FR rubber conveyor belt
1.Suitable for conveying hot material like powder or clump materials at high temperature.
2.Ideal for conveying sintered ores, cokes, soda ash, chemical fertilizer, slag and foundry.
3.It can resist high temperature.
4.The rubber compound used in the cover have been designed to avoid premature aging due to contact with any source of heat.
Specification Availability:
Belt type |
Fabric type |
Single Fabric strength (N/mm) |
Rubber cover thickness (mm) |
Ply |
Belt width (mm) |
|
Top rubber |
Bottom rubber |
|||||
|
Cotton Canvas (CC) conveyor belt |
CC-56 |
56 |
3-18 |
1.5-10 |
2-10 |
300-2500 |
|
Nylon (NN)/Polyester(EP) conveyor belt |
NN/EP-80
|
80 |
||||
NN/EP-100 |
100 |
|||||
NN/EP-125 |
125 |
|||||
NN/EP-150 |
150 |
|||||
NN/EP-200 |
200 |
|||||
NN/EP-250 |
250 |
|||||
NN/EP-300 |
300 |
|||||
NN/EP-400 |
400 |
|||||
NN/EP-500 |
500 |
|||||
NN/EP-600 |
600 |
|||||
Rubber Cover Grade & Standard No:
| Standard No | Cover rubber | |||
| Tensile strength MPa | Elongation at break % | Abrasion mm3 | ||
| DIN22102 | Z | 15 | 350 | 250 |
| W | 18 | 400 | 90 | |
| Y | 20 | 400 | 150 | |
| X | 25 | 450 | 120 | |
| AS1332 | N17 | 17 | 400 | 200 |
| N24 | 24 | 450 | 125 | |
| RMA | I | 17 | 400 | |
| II | 14 | 400 | ||
| SANS1173 | A | 18 | 400 | 70 |
| C | 20 | 400 | 150 | |
| M | 25 | 450 | 120 | |
| N | 17 | 400 | 150 | |
Classfication by use:
Type |
Rubber Cover Type |
Tensile strength at break(N/mm2) |
Elongation at break % |
Abrasion mm3 |
|
Abrasion Resistant |
RCB-AR-M |
24 |
450 |
120 |
RCB-AR-Y |
20 |
400 |
150 |
|
RCB-AR-W |
18 |
400 |
90 |
|
RCB-AR-N18 |
18 |
450 |
200 |
|
RCB-AR-N |
17 |
400 |
200 |
|
RCB-AR-A |
17 |
400 |
70 |
|
RCB-AR-Z |
15 |
400 |
250 |
|
RCB-AR-II |
14 |
350 |
280 |
|
RCB-AR-L |
10 |
350 |
300 |
|
|
Oil Resistant |
RCB-FOR |
12 |
300 |
300 |
RCB-MOR |
15 |
450 |
250 |
|
RCB-LOR |
17 |
450 |
200 |
|
|
Heat Resistant |
RCB-HR-T1-100oC |
17 |
400 |
250 |
RCB-HR-T2-125oC |
15 |
350 |
250 |
|
RCB-HR-T3-150oC |
13 |
350 |
250 |
|
RCB-HR-T4-180oC |
11 |
350 |
280 |
|
RCB-HR-T5-300oC |
10 |
350 |
300 |
|
|
FR/AR/AS Resistant |
RCB-ARAS |
18 |
450 |
200 |
RCB-FRAS |
14 |
400 |
250 |
|
RCB-FR |
12 |
350 |
300 |
|
|
Cold Resistant |
RCB-CR-T1-- -30oC |
17 |
350 |
300 |
RCB-CR-T2-- -50oC |
14 |
300 |
300 |
|
|
Chemicl Resistant |
RCB-ANTI-ACID |
14 |
400 |
250 |
RCB-ANTI-ALKALI |
14 |
400 |
250 |
Packaging Detail:
wooden core cover with pp-cloth or according to the customers' needs.
Shipment
a. By express/air: small quantity order.
b. By sea: container load.
Delivery Detail:
about 20 working days from order.
Loading port
Ningbo/ Shanghai.
View more products, please click on images below:
Gold Camel Industrial Co.,Ltd. , Zhejiang Three-V Imp. & Exp. Co., Ltd.
Having specialized in mechanical conveyor systems products for more than 15 years,Jinhua Gold Camel Industrial Co.,Ltd has became an experienced and professional supplier in this field.In the year of 2009,to seize more progressive development,Gold Camel got combined with Zhejiang Three-V Industry Group,which is a key Conveyor System & Rubber products manufacturer of about 20 years history in China.
Our products are designed and produced under ISO9001 system and strict quality control,which covers various kinds of Conveying System and Fittings, especially Rollers&Pulleys, Chains&Sprockets, Rubber Conveyor Belts, V-belts,Timing Belts,Flat Transmission Belts,Fasteners and Clamps; Elevator & Fittings,specially HDPE/Metal Bucket,Screw Flights,Crusher Machines and Fittings,ect.
T/T/ Western Union/ MoneyGram/ Paypal/L/C at sight/ Alipay/ D/A/ D/P: 30% in advance, balance before loading the goods. Other payment terms can be negotiated.
2.Prices
PRICE just for reference. The final prices (FOB, CIF, CNR) prices are according to order quantity, payment terms, delivery time, packaging, etc.
FAQ:
1.Is OEM available?
Yes, OEM is available. We have professional designer to help your brand promotion.
2.Is the sample available?
Yes, samples are available for you to test the quality.If we have samples in warehouse,freight can be paid by your side.
3.Are the products tested before shipping?
Yes, all of our tire and tube was qualified before shipping. We test every batch every day.
4.What’s benefit will you bring?
Your client satisfied on the quality.
Your client continued orders.
Your can get good reputation from your market and obtain more orders.
