Help CenterCar Upper&Lower Radiator Rubber Hose/Silicone Hose/Fuel Hose/Air Intake Hose/Intercooler Hose/Flexible Hose/Heater Breather Hose
Related Products
-
Automotive Radiator Rubber HosesUS$ 0.25 - 0.65MOQ: 300 Pieces -
Car Upper&Lower Radiator Rubber HosesUS$ 0.25 - 0.65MOQ: 300 Pieces
-
Auto Rubber Upper & Lower Radiator HoseUS$ 0.25 - 0.65MOQ: 300 Pieces
-
Automotive Radiator Rubber Hoses (OEM NO. 17127510952 ,11531436406, 11534460438,etc)US$ 0.25 - 0.65MOQ: 300 Pieces
-
Upper Radiator Hose for "Chevrolet Opel" 93396320US$ 0.25 - 0.65MOQ: 500 Pieces
Company:HeBei HongAn Automobile&Motorcycle Fittings Co.,Ltd.
Website: Http://
We produce many products,such us: Rubber Seals,Rubber Hose,Molded Rubber Products, Air Filters,Plstic Parts(Clips and Fasteners), Control Cables,etc
Brands: PINLIDE
Number of Employees: 51 - 100 People
Trade & Market
Main Markets:
North America
South America
Eastern Europe
Southeast Asia
Africa
Oceania
Mid East
Western Europe
Central America
Northern Europe
Southern Europe
South Asia
Total Annual Sales Volume:
US$2.5 Million - US$5 Million
Export Percentage: 81% - 90%
Factory Information
Factory Size (ters):
10,000-30,000 square meters
Factory Location: North of Dazhai Road, Qinghe County, Hebei Province
Number of Production Lines: 4
Number of R&D Staff: 5 - 10 People
Number of QC Staff: 11 - 20 People
Management Certification: ISO/TS16949
Contract Manufacturing: OEM Service Offered Buyer Label Offered
We can produce the products according to the sample or drawings to meet customer requirements.
If you have any questions, you can send me email or call me at any time.And chat with me in alibaba.(cn1511549500)
Ph: +86 15731139076 +0319-813 2299
wechat/QQ:972472162
Skype:wang.angel25 (Angel Wang)
routine plastic film, carton. But according customers requirement, adjustment packing.
Premium construction SAE 20R3 and R4 class D1 and D2 is a high quality coolant hose designed to offer extra long service life on automotive and truck cooling system applications.
This hose is constructed EPDM tube and cover with two spiral layers of reinforcement.SAE 20R3 D1&D2 is a Heater Hose,SAE 20R4 D1 is a radiator hose.Both are intended to operate in the range -40℃~+125℃(-40℉~+257℉).
Long service life since hoses can withstand the abuse of corrosive additives,ozone and abrasion.Supplied in both straight and custom formed shapes.
Specifications
Car Coolant System Radiator Hose
EPDM Rubber Construntion
Coolant Resistance
Ozone Resistance
High Temperature Resistance
- High Temperature Resistance (- 40 °C to 120 °C)
- Coolants and Water Resistance
- Sunlight, Ozone, Weatherability Resistance
- Chemicals Resistance
Automotive Radiator Coolant Hose Construction:
- Tube: EPDM rubber compound
- Reinforcement: polyester or steel wire or aramid
- Cover: EPDM rubber compound
- Upper Radiator Hose
- Lower Radiator Hose
- Bypass Hose
- Heater Hose
- Oil Cooler Hose
- Fuel Hose
- Outside Braided Fuel Hose
- Breather Hose
- Vent Hose
- Silicone Hose
- Washer Vacuum Hose
- Intercooler Hose
- Flexible Radiator Hose
- Air Intake Hose
Other Silicone Hose Information
Silicone Heater Hose Material Standard: Meet the requirements of the SAEJ20R1 class A
Property |
Specification |
|
Durometer, points Shore A |
70+/-5 |
|
Tensile, min, MPa |
7.6 |
|
Elongation, min, % |
280 |
|
|
Oven Aging 70h at 175°C Change of
|
Durometer, points Shore A |
+15 |
Tensile, % |
-10 |
|
Elongation, % |
-25 |
|
|
Coolant Immersion(Tube) 70h at boiling point Change of |
Volume, % |
10 |
Durometer, points Shore A |
+10 |
|
Tensile, max, % |
-20 |
|
Elongation, max, % |
-16 |
|
Long service life since hoses can withstand the abuse of corrosive additives, ozone and abrasion.Supplied in both straight and custom formed shapes.
