Heat resistant wire mesh conveyor belt
ST Series:
1.Belt reinforced with galvanized steel cord and core rubber with superior adhesive property.
2.Steel cord made of left and right twisting wire arranged evenly and longitudinally in the belt.
3.Large tensile strength,excellent trough-ability and excellent flexing resistance.
GX Series:
1.Cord has enough room to allow penetration of core rubber.
2.Better bondng between rubber and steel cord, giving better anticorrosive resistance,dynamic fatigue resistance of steel cord, leading to longer service life.
Specification Availability:
| Referenced belt specifications | st630 | st800 | st1000 | st1250 | st1600 | st2000 | st2500 | st3150 | st3500 | st4000 | st4500 | st5000 | st5400 | st6300 |
| tensile strength N/mm | 630 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3150 | 3500 | 4000 | 4500 | 5000 | 5400 | 6300 |
| diameter of cord(mm) | 3 | 3.5 | 4.1 | 4.9 | 5.6 | 5.6 | 7.2 | 8.1 | 8.6 | 8.9 | 10.9 | 9.7 | 11.3 | 12.3 |
| pitch(mm) | 10 | 10 | 12 | 14 | 15 | 12 | 15 | 15 | 15 | 15 | 16 | 17 | 17 | 18 |
| min thickness of cover(mm) | 4 | 4 | 4 | 4 | 4 | 4 | 5 | 5.5 | 6 | 6.5 | 7 | 7.5 | 8 | 9 |
| top rubber cover thickness(mm) | 5 | 5 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8.5 | 9 | 9 |
| bottom rubber cover thickness(mm) | 5 | 5 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8.5 | 9 | 9 |
| width(mm) | cord number | |||||||||||||
| 500 | 47 | 47 | 39 | 34 | - | - | - | - | - | - | - | - | - | - |
| 650 | 61 | 61 | 51 | 44 | 40 | 51 | 40 | 40 | 40 | 40 | 37 | - | - | - |
| 800 | 75 | 75 | 64 | 55 | 50 | 64 | 50 | 50 | 50 | 50 | 46 | 43 | 43 | - |
| 1000 | 79 | 79 | 81 | 69 | 64 | 81 | 64 | 64 | 64 | 64 | 59 | 55 | 55 | 54 |
| 1200 | 113 | 113 | 97 | 84 | 77 | 97 | 77 | 77 | 77 | 77 | 71 | 66 | 66 | 63 |
| 1400 | 133 | 133 | 114 | 98 | 90 | 114 | 90 | 90 | 90 | 90 | 84 | 78 | 78 | 74 |
| 1600 | 151 | 151 | 131 | 112 | 104 | 131 | 104 | 104 | 104 | 104 | 96 | 90 | 90 | 85 |
| 1800 | 171 | 171 | 147 | 127 | 117 | 147 | 117 | 117 | 117 | 117 | 109 | 102 | 102 | 96 |
| 2000 | 191 | 191 | 164 | 141 | 130 | 164 | 130 | 130 | 130 | 130 | 121 | 113 | 113 | 107 |
| 2200 | - | - | 181 | 155 | 144 | 181 | 144 | 144 | 144 | 144 | 134 | 125 | 125 | 108 |
| 2400 | - | - | 197 | 169 | 157 | 197 | 157 | 157 | 157 | 157 | 146 | 137 | 137 | 129 |
| 2600 | - | - | 214 | 184 | 170 | 214 | 170 | 170 | 170 | 170 | 159 | 149 | 149 | 140 |
View more products, please click on images below:
Having specialized in mechanical conveyor systems products for more than 15 years,Jinhua Gold Camel Industrial Co.,Ltd has became an experienced and professional supplier in this field.In the year of 2009,to seize more progressive development,Gold Camel got combined with Zhejiang Three-V Industry Group,which is a key Conveyor System & Rubber products manufacturer of about 20 years history in China.
Our products are designed and produced under ISO9001 system and strict quality control,which covers various kinds of Conveying System and Fittings, especially Rollers&Pulleys, Chains&Sprockets, Rubber Conveyor Belts, V-belts,Timing Belts,Flat Transmission Belts,Fasteners and Clamps; Elevator & Fittings,specially HDPE/Metal Bucket,Screw Flights,Crusher Machines and Fittings,ect.
