Specifications
1. size: 4X4 5X5 10X10 etc2.Roll size:1x20m,50m-300m
3.Weight: 60-300g
4.High strength&many color choice
fiber glass mesh
fiber glass mesh characteristics:
1. Good chemical stability: Alkali-resistant, acid-resistant, waterproof,cement erosion-resistant, and other chemicals' corrosion resistant; and strong resin bonding, soluble in styrene.
2. Outstanding craftsmanship include coating enough alkali-resist glue, our coating glue is produced by Germany BASF which can keep 60-80% strength after test in NAOH 28days later, so that guarantee high strength, high tensility, light weight.
3. Strength retention rate> 90%, elongation <1%, the durability of more than 50 years
4. Good dimensional stability, stiffness, smoothness an difficult to shrink and deformation, good positioning property
5. Good impact resistance and not easy to be teared.
6. Fire resistant, thermal insulation, sound insulation etc.
fiber glass mesh Application:
1. Wall reinforced material (such as fiberglass wall mesh, GRC wall panels, EPS insulation with the wall board, gypsum board, bitumen etc)
2. Reinforced cement products.
3. Used for Granite, mosaic, marble back mesh etc.
4.Waterproof membrane fabric, asphalt roofing.
5. Framework material for reinforced plastics, rubber products,.
6. Fire board.
7. Grinding wheel base fabric.
8. Road surface with geogrid
9. Construction caulking tape etc.
fiber glass mesh Useage:
1. 75g / m2 or less: Used in the reinforcement of thin slurry, to eliminate small cracks and scattered throughout the surface pressure.
2. 110g / m2 or about: Widely used in indoor and outdoor walls, prevent the various materials (such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion coefficient of wall crack and break .
3. 145g/m2 or about: Used in the wall and be mixed in various materials (such as brick, light wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure, especially in the external wall insulation system (EIFS ).
4. 160g / m2 or about: Used in insulator layer of reinforcement in the mortar, through shrinkage and temperature changes by providing a space to maintain movement between the layers, prevent crack and rupture due to shrinkage or temperature change.
Specifications:
Products |
Weight (g/s.q) |
Cell size (mm) |
Roll size (ters) |
quantity of rolls in one container 40HQ |
Color |
Package |
|
Fiberglass Mesh
(fiberglass net) |
60g |
4*4---10*10mm
|
1m*50m |
4000 rolls |
White
Blue
Yellow
Black
Red
Green,
etc. |
Bulk, plastic, carton or as your demand |
70g |
1m*50m |
3500 rolls |
||||
80g |
1m*50m |
3000 rolls |
Certification |
|||
90g |
1m*50m |
2900 rolls |
||||
100g |
1m*50m |
2800 rolls |
ISO9001:2008 |
|||
110g |
1m*50m |
2700 rolls |
MOQ |
|||
120g |
1m*50m |
2600 rolls |
75000 or one container |
|||
130g |
1m*50m |
2550 rolls |
||||
140g |
1m*50m |
2500 rolls |
Delivery time |
|||
150g |
1m*50m |
2450 rolls |
||||
160g |
1m*50m |
2400 rolls |
25-30days |
|||
Application |
Heat insulation material. protection and strengthen of wall structure , protect the surface of marble and granite, widely used to reinforce cement .stone ,wall material and roof |
|||||
We can produce any size mesh according to requirements of customer like different mesh size and weight per square meter.
Please don't hesitate to contact us! You will be pleased with the quality. I can offer you good quality.
Our factory:
Products:
Details:
Packing:
Loading:
