Remax-1212 cnc routers for cutting metals
Application
Used for the processing of metal mould ,graphite electrode, mobile phone, camera and MP3.
Features
1. whole cast-iron structure, steady structure, high rigidity,precision 0.01mm.
2. Three axis all use Germany ball screw and Taiwan linear orbits, also installed with Japan bevel math bearing for ball screw to make sure the accuracy and reposition precision.
3. NCStudio control system, This system has break point memory mode and special saving mode of different points, so that can make sure continuous working after electronic drop or other postpone situation. The function can guarantee the processing precision of long time operation.
4. Adopt high-speed water cooling variable frequency motor, big torque, strong cutting, high-frequency , long-lifetime, can be a long time continuous working .
Parameter:
| Description | Parameter |
| X,Y,Z Working Area | 1200x1200x100mm |
| X,Y,Z Traveling Positioning Accuracy | ±0.01/300mm |
| X,Y,Z Repositioning Accuracy | ±0.025mm |
| moving mode | table moving |
| Frame | cast by iron |
| X, Y, Z Structure | Hiwin Rail Linear Guide and TBI ball screw |
| Z Structure | Hiwin Rail Linear Guide and TBI Ball Screw |
| Max. Power Consumption | (Without Spindle) 2kw~3Kw |
| Max. Rapid Travel Rate | 25000mm/min |
| Max. Working Speed | 18000mm/min |
| Spindle Power | 3.0KW constant water cooling spindle |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Stepper Motor |
| Working Voltage | AC380V/50/60Hz,3PH (Option: 220V) |
| Command Language | G Code |
| Operating System | DSP System (Options: Ncstudio/Mach3 PC Software) |
| Computer Interface | USB |
| Flash Memory | 128M(U Disk) |
| Collet | ER25 |
| X,Y Resolution | <0.01mm |
| Software Compatibility | Type3/UcancameV9 Software, (Option: Artcam Software) |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
| Inverter | Delta/Fuling |
| Electrical components | Schneider |
| Limit switch | OMRON |
| Driver | YASKAWA 850w from Japan |
Main components
Samples
Shipping
our services
A Guarantee:
1.12 months for the whole machine.
2.Within 12 months under normal use and maintenance,
3.if something is wrong with machine, you will get spare part for free.;
4.Out of 12 months, you will get spare part at cost price.
5.You will also get technical support and service all the lifetime.
B After sales services:
1.Normal machine is properly adjusted before dispatch.
2.You will be able to use the machines immediately.
3.You will be able to get free training advice towards our machine in our factory.
You will also get free suggestion and consulting, technical support and service by
4.email/fax/tel and lifetime technical support.
Exhibition
CE certificate:
FAQ:
A This is the first time I use this kind of machine, is it easy to operate?There are english manual or teaching video that show how to use machine.
If there is still have any question, please contact us by email / skype/ phone /trademanager online service at any time.
B If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period if machine have any problem.
If the parts less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
C MOQ ?
The minimum order is 1 set machine, if you order more one time, the price will be better.
D How can I buy this machine from you? ( Very easy and flexible !)
1. Consult us about this product on line or by e-mail.
2. Negotiate and confirm the final price , shipping , payment methods and other terms.
3. Send you the proforma invoice and confirm your order.
4. Make the payment according to the method put on proforma invoice.
5. We prepare for your order in terms of the proforma invoice after confirming your full payment. And 100% quality check before shipping.
6. Send your order by air or by sea.
E 10 good reasons why you should buy from us?
1 we are a real factory offering products
2 free technical advice by QUALIFIED MECHANICAL ENGINEERS
3 company in business for many years
4 over 50 countries customers served!
5 buy direct saving your money!
6 all machine with CE, ISO, BV certificate.
7 machine and spindle warranty 1 year.
8 our engineer can go to your country to provide technical guidance
9 we have phone support in English, if you have any questions, you can call it, we can give you a best solution within 24 hours
10 fast delivery, save your time.
THANKS FOR VISITING THE PRODUCT OF REMAX AND IF YOU HAVE ANY QUESTION PLEASE CONTACE ME!
