Universal Used CNC Wood Cutting Machine For Kinds Of Shapes
- 600 Set / Sets per Month
- shanghai
- T/T Credit Card
Product Details
Condition: | New | Place of Origin: | Hubei, China | Brand Name: | JOY |
Model Number: | JOY1325 | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
plywood case
Product Description
Universal Used CNC Wood Cutting Machine For Kinds Of Shapes
Detailed Product Description
1.CNC Wood Cutting with 4.5kw spindle power is mainly applied in wood working industry, furniture industry for furniture decoration, wooden door and window frame processing, and wooden handcraft making industry, manufacturing sewing machine table and cabinet panels, etc.
2.Wood CNC Router are not exclusively applicable for wood engraving, wood cutting ;but also can be sued for engraving on Acrylic Engraving, Acrylic Cutting, PVC Engraving, PVC Cutting ,Stone Engraving, Stone Cutting, Metal Engraving, Metal Cutting, etc.
Description(JOY1325) | |
X,Y,Z working area | 1300x2500x120mm
|
X,Y,Z traveling position accuracy | <=0.1mm |
X,Y,Z reposition accuracy | <=0.1mm |
Table surface | PVC |
Lathe bed | Cast |
X,Y transmission | High accuracy gear rack |
Z transmission | Imported ball screw |
Max power consumption(without spindle) | 12kw |
Max travel speed | 30000m/min |
Max working speed | 20000m/min |
Spindle power motor | 4.5kw |
Spindle speed | 24000r/min |
Driver system | Step motor |
Working voltage | 380V/220V |
Command language | G code |
Operation system | DSP |
Interface | USB |
Flash memory | 128M |
Collect | 3.175-12.5 |
X,Y resolution | <=0.1mm |
Software | UCANCAM, Type3 |
CNC Wood Machine Special Features:
1) Using Professional Dust Collecting System (for Cutting Wood) and Vacuum System (for absorbing objects)
2) Advanced digit-control system, handle operation and large liquid crystal display brings out more convenient operation, simpler maintenance and more human nature on the design of the machine.
3) The three axes use linearity square guide rail and drive which could meet different cutting demand and has high cutting precision.
4) Unique intelligent calculation fully develops the potential of the electric machinery and leads to high speed processing, the synchronization of curves and straight lines, smoother curves and race speed at 12m/min.
5) Large internal memory capacity of 32M is able to store 30 processing files simultaneously and open and process any of them.
This model uses domestic-leading PCI controlling system. It uses imported square shape guide rail and the transmission is steady. It adopt high-precision level gear transmission, the maximum speed can reach 30m/m. It can engrave the graph of 1.5*1.5mm clearly.
7) It equipped with aluminum work table with special design, which can endure much weight. On the base of PEM-1325A, it uses the vacuum work table, which can adsorb the wood dust, and make the environment clean. And it adopts a more advance XYZ Auto-oil-feeding system.
Samples:
If you have questions ,pls don't hesitate to email to us !
Company Profile
Company Description
Wuhan King Suntime CNC Equipment Co.LTD. is a professional manufacturer of industrial CNC equipment,which located in "Optics Valley" , Wuhan city, China. Our company principle is to produce the first class products, create perfect services.
Products
Our products include: inkjet printing machines, Laminator machines, cnc plasma cutters, CNC letter bending machine, acrylic bending machines,cnc notching machine, cnc router, cnc glass engraving machine, cnc laser engraving and cutting machines, cnc laser welding machines and so on. Personalized products and services to provide customers best machines, our machines are widely used in outdoor indoor advertising , signs, printing, metal cutting industry, woodworking, glass industry, leather, clothing industrial, craft gift as well as more industries.
Certificate
Our printer machines, plasma cutting machines, cnc router machine, cnc letter bending machine,cnc laser welding machines all have got CE certification. High precision, low energy consumption, automatic processing.
Technical Team
We have two R & D base in Wuhan City, well-known institutions of higher learning and research institutions at home and abroad, a number of the core technological achievements and technical indicators at the international advanced level.
Machine Testing
To ensure the quality and stability of the machine, we use the most advanced production and testing equipment ,to check the quality and performance of our industrial cnc equipment in each production step to ensure our equipment quality and stable performance.
Quality
In order to guarantee the performance and quality of our products, we strictly controls all processes, including processing, assembly and delivery.
Export
our products are not only sold in China in large quantity , but also have been exported to more than 120 countries and regions in the world, including: Germany, America ,Italy, Russia, South Korea, Turkey, Brazil , South Africa, India, the United Arab Emirates,and so on.
Service:
sell the best machines at the best prices, and provides industry-leading customer service. Our technical engineers provide comprehensive pre-sale and after-sale support and service all the time.
