Multi-heads Woodworking Machine for Mdf

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

joy

Model Number:

joy1212

Wuhan King Suntime CNC Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name joy

Model Number joy1212

Specifications

multi-heads woodworking machine for mdf
1.5kw water cooling spindle
high speed stepper motor
Taiwan linear guide rail
CE

multi-heads woodworking machine for mdf

Detailed Product Description

1. Rotary attachment is optional, which enable the machine to engrave on column workpieces
2.Equipped with 2 to 4 heads

Features:

* Equipped with 2 to 4 heads; the machine one time can complete the works done by several machines, to save cost and improve the working efficiency.

* The distance between heads can be adjusted according to the working pieces being processed.

* It is possible to start any one of the heads only.

* Spindle power is selected according to customer’s requirements.

* Rotary attachment is optional, which enable the machine to engrave on column work-pieces like table leg.

* Especially firm structure and special design on details make the machine to achieve

Description
X,Y,Z working area	1200x1200x100mm (47.2x47.2x3.9 inch) 1300x1800x100mm (51.2x70.9x3.9 inch) 1300x2500x200mm (51.2x98.4x7.9 inch)
X,Y,Z traveling position accuracy	<=0.1mm
X,Y,Z reposition accuracy	<=0.1mm
Table surface	PVC
Lathe bed	Cast
X,Y transmission	High accuracy gear rack
Z transmission	Imported ball screw
Max power consumption(without spindle)	12kw
Max travel speed	30000m/min
Max working speed	20000m/min
Spindle power motor	1.5kw 2, 1.5kw3, 1.5kw4,1.5kw5
Spindle speed	24000r/min
Driver system	Step motor
Working voltage	380V/220V
Command language	G code
Operation system	DSP
Interface	USB
Flash memory	128M
Collect	3.175-12.5
X,Y resolution	<=0.1mm
Software	UCANCAM, Type3
