jinan Remax high quality woodworking 4 axis cnc routers factory directly perfect made by your require
- 100 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T Credit Card PayPal
- Remax-1224 5 Axis CNC Router Machine, Wood Router CNC 5 Axis With Best Price
- Remax-1325 4 Axis Wood CNC Router Machine, Wood Router CNC 4 Axis
- Remax-1224 5 Axis CNC Router Machine, 5 Axis Wood Engraving Machine + 3D Scanner
- Remax-1224 5 Axis Wood CNC Router Machine, Wood Router CNC 5 Axis Machine
- Remax-1224 5 Axis CNC Machine Router, 5 Axis Wood Engraving Machine
- Remax-1325 4 axis rotary wood cnc router
Product Details
Condition: | New | Type: | CNC Router | Use: | Marble |
Production Capacity: | 30m/min | Place of Origin: | Shandong, China | Brand Name: | remax |
Model Number: | 1530 | Voltage: | 380v | Power(W): | 4.2kw |
Dimension(L*W*H): | 3500*2100*1600mm | Weight: | 2700kg | Certification: | CE ISO BV |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
wood packaging or according customer's requirement
Product Description
jinan Remax high quality woodworking 4 axis cnc routers factory directly perfect made by your require
Product description:
1. 4 axis cnc router , is specially for 4D work , the A axis can rotate +/- 90 degree
2.The machine's main parts are all from world famous suppliers, such as Syntec control system, Yaskawa servo motors, Sampo reducer, HSD spindle, Delta inverter and Becker vacuum pump, all components are from global leaders.
3.With this machine, you can make different surface carving, arc-surface milling, bend surface machining for 4D jobs, like special shaped arts, bended doors or cabinets.
4.It can work on foam, MDF, Acrylic, wood, and the soft metal etc.
Technical Parameter:
Index | Parameter |
X,Y,Z, AWorking Area | 1500x3000X400mm ±90° |
Table Size | 2940X1490mm |
X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
X,Y,Z Repositioning Accuracy: | ±0.03mm |
Table Surface | Integrated Vacuum and T-slot Combined (Option: T-slot Table) |
Frame | Precision machined & heavy duty frame (stress-relieved),one-piece steel base |
X, Y Structure | Rack and Pinion Drive, Hiwin Rail Linear Bearings |
Z Structure | Hiwin Rail Linear Bearings and TBI Ball Screw |
Max. Power Consumption | (Without Spindle) 4.5Kw |
Max. Rapid Travel Rate | 50000mm/min |
Max. Working Speed | 30000mm/min |
Spindle Power | 4.5/6.0/7.0/9.5/12.0 Kw HITECO ATC(optional HSD ) |
Spindle Speed | 0-24000RPM |
Drive Motors | Yaskawa Motors |
Working Voltage | AC380V/50/60Hz,3PH |
Command Language | G Code |
Operating System | Syntec EZ-4M Control System/10B |
Computer Interface | CF card, Ethernet |
Flash Memory | 256M |
Tool holder | HSK F63 |
X,Y Resolution | <0.03mm |
Software Compatibility | Type3, UcancameV9 software ( UG software/Power mill) |
Running Environment Temperature | 0 - 45 Centigrade |
Relative Humidity | 30% - 75% |
Packing Size | 3400X3500X2800mm |
N.W. | 2600KG |
G.W. | 2800KG |
Optional Parts | Lucbricating system |
Vacuum Pump | |
Mist-cooling System | |
Positioning air cylinder |
Machine Parts:
1.Remax4-1325,C axis with angular head CNC router , incorporates a 9.5kw Italian-made ATC spindle and 90° angular head with C Axis, it is a combination for both three axis vertical machining and the horizontal machining by C Axis (4th Axis). The machine is capable to finish a true 3D structure in a single setup. The ideal material for this machine including foam, wood, plastics, composite resin….
2. With Precision machined & heavy duty frame, stress relieved in a rigorous thermal treatment, hence, the 4 Axis CNC is allows a 500-1000mm large Z travel, and offers accurate and smooth machining effect without vibration.
3. Motion by helical rack and gear on X and Y, imported high-precision ball screw on Z Axis, which moving smoothly, to ensure the machine’s high precision.
4. High-performance Japanese Yaskawa servo system with planetary gear reducers to ensure the machine’s high speed and accuracy.
5. Advance 4 Axis control system, auto-complete multilevel 3D processing, carving or cutting. Meanwhile, offline operation can be realized.
6. Original industrial standard HSK tool holders, Taiwan made Carousel tool magazine with 8 positions plus T9 the angle head position.
7. Standard configuring with auto lubrication system, automatic tool setting system.
8. Top quality accessories, to minimize the machine’s failure rate,Well-known electrical parts Schneider, Omron, Honeywell, etc., Pneumatic components Taiwan AirTAC.
sample
