Home > Manufacturing & Processing Machinery > Woodworking Machinery > Wood Router > Remax-1530 4 Axis CNC Router Machine Used for Woodworking

Remax-1530 4 Axis CNC Router Machine Used for Woodworking

Name: Remax-1530 4 Axis CNC Router Machine Used for Woodworking
Brand: Remax
SKU: 103818079
Availability: InStock

Remax-1530 4 Axis CNC Router Machine Used for Woodworking thumbnail-1

Remax-1530 4 Axis CNC Router Machine Used for Woodworking thumbnail-2

Remax-1530 4 Axis CNC Router Machine Used for Woodworking thumbnail-3

Remax-1530 4 Axis CNC Router Machine Used for Woodworking photo-1

Remax-1530 4 Axis CNC Router Machine Used for Woodworking photo-2

Remax-1530 4 Axis CNC Router Machine Used for Woodworking photo-3

US$ 16,000 - 30,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Jinan Remax Machinery Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name Remax

Model Number 1530

Voltage 380v

Power(W) 4.2kw

Dimension(L*W*H) 3500*2100*1600mm

Weight 2700kg

Certification CE,ISO,BV

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

4 axis cnc router
Syntec system
YASKAWA servo motor
HSD Spindle
Hiwin square rails

4 axis cnc router machine

Product description:

1. 4 axis cnc router , is specially for 4D work , the A axis can rotate +/- 90 degree

2.The machine's main parts are all from world famous suppliers, such as Syntec control system, Yaskawa servo motors, Sampo reducer, HSD spindle, Delta inverter and Becker vacuum pump, all components are from global leaders.

3.With this machine, you can make different surface carving, arc-surface milling, bend surface machining for 4D jobs, like special shaped arts, bended doors or cabinets.

Parameter:

Index	Parameter
X,Y,Z, AWorking Area	1500x3000X400mm ±90°
Table Size	2940X1490mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
X,Y,Z Repositioning Accuracy:	±0.03mm
Table Surface	Integrated Vacuum and T-slot Combined (Option: T-slot Table)
Frame	Precision machined & heavy duty frame (stress-relieved),one-piece steel base
X, Y Structure	Rack and Pinion Drive, Hiwin Rail Linear Bearings
Z Structure	Hiwin Rail Linear Bearings and TBI Ball Screw
Max. Power Consumption	(Without Spindle) 4.5Kw
Max. Rapid Travel Rate	50000mm/min
Max. Working Speed	30000mm/min
Spindle Power	4.5/6.0/7.0/9.5/12.0 Kw HITECO ATC(optional HSD )
Spindle Speed	0-24000RPM
Drive Motors	Yaskawa Motors
Working Voltage	AC380V/50/60Hz,3PH
Command Language	G Code
Operating System	Syntec EZ-4M Control System/10B
Computer Interface	CF card, Ethernet
Flash Memory	256M
Tool holder	HSK F63
X,Y Resolution	<0.03mm
Software Compatibility	Type3, UcancameV9 software ( UG software/Power mill)
Running Environment Temperature	0 - 45 Centigrade
Relative Humidity	30% - 75%
Packing Size	3400X3500X2800mm
N.W.	2600KG
G.W.	2800KG
Optional Parts	Lucbricating system
	Vacuum Pump
	Mist-cooling System
	Positioning air cylinder

1.Remax4-1325,C axis with angular head CNC router , incorporates a 9.5kw Italian-made ATC spindle and 90° angular head with C Axis, it is a combination for both three axis vertical machining and the horizontal machining by C Axis (4th Axis). The machine is capable to finish a true 3D structure in a single setup. The ideal material for this machine including foam, wood, plastics, composite resin….

2. With Precision machined & heavy duty frame, stress relieved in a rigorous thermal treatment, hence, the 4 Axis CNC is allows a 500-1000mm large Z travel, and offers accurate and smooth machining effect without vibration.

3. Motion by helical rack and gear on X and Y, imported high-precision ball screw on Z Axis, which moving smoothly, to ensure the machine’s high precision.

4. High-performance Japanese Yaskawa servo system with planetary gear reducers to ensure the machine’s high speed and accuracy.

sample

Factory show

FAQ:

A This is the first time I use this kind of machine, is it easy to operate?

There are english manual or teaching video that show how to use machine.
If there is still have any question, please contact us by email / skype/ phone /trademanager online service at any time.

B If machine have any problem after I receive it, how can I do ?

Free parts send to you in machine warranty period if machine have any problem.
If the parts less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.

C MOQ ?

The minimum order is 1 set machine, if you order more one time, the price will be better.

CE certificate:

Packing:

Standard wood packing or according customer requirement

THANKS FOR VISITING THE PRODUCT OF REMAX AND IF YOU HAVE ANY QUESTION PLEASE CONTACE ME!
