JOY-1925 CNC Glass Engraving Machine With auto polishing tools
CNC Glass Engraving Machine
glass engraver machine with auto polishing
glass engraving with polishing
We are only one can produce high speed cnc glass engraving machine in china. If you have any questions,pls feel free to contact me, i will give you the professional suggestions with 5 hours
Detailed information for CNC glass engraving machine
CNC glass engraving machine, the new generation of glass processing equipment our company has developed lately, adopts the computer aided design system, jointly designed by a number of senior engineers and technicians. The machine is equipped with high - quality ball screw, slideway in Germany, and japan's Mitsubishi servo motor. It is controlled by the computer and is able to assign the tools library as well as the tool changing system according to the reqirements. The machine is widely applied in glass and mirror grooving, polishing from the designing to processing.
Advantages:
1. Unique graphic simulation capabilities enables the user to see the sample to be processed easily, significantly decreasing the error rate during processing.
2. Long wheel utilization, tool grinding wheels can working on170 -110, nearly two times of that of the same kind in china, which greatly reduces the production cost for the customer.
3. Both English and Chinese are available, easy to learn and operate.
Technical parameters:
Model |
JOY 1925 |
X,Y,Z working area |
1900×2500×300mm |
Allocating Accuracy (C axis) |
0-360 |
Location precision |
(X, Y, Z axis) 0.10×0.10×0.02mm |
Repeatability |
(X, Y, Z axis) 0.05×0.05×0.01mm |
Z aixs |
10m/min |
Main axle rotating speed |
4000rpm |
Main axle rotating rate |
4kw |
Max grooving depth |
6-30mm |
Engraving speed |
3m/min |
Voltage |
220V/380V |
Thickness of glass |
3-30mm |
Max diameter of the knife |
Φ170mm |
Gross power |
10kw |
Description:
---Specification: Model 1925 (table size: 1900*2500mm)
---Delivery time: in 20 working days
---Min Quantity: 1set
---Country of origin: China
---Terms of Payment: 30% by T/T in advance, rest 70% by T/T before shipment
One-year after-sales service:
1. We will offer some of the parts for free in the first year. The buyer needs to pay for the shipping cost for the parts. The user needs to send us pictures of the broken one, then we will send out the part they need.
2. In the first year, if the buyer needs our engineers to come to the local to fix some problems of the machine that they cannot fix by themselves; we will send our engineers for free. The buyer needs to pay the flights, housing and meals for the engineers in the local.
3. We will offer our service through email and phones if the buyer needs any help on technical problems.
