Best Price For 48 port wall mount patch panel
Low cost modular odf
1.Application
modular odf is used in center office, optical cross connection point and network access point in fiber access network projects to realize the fiber fusion, fiber optic cable distribution, management and protection. The unit is installed in the optical distribution frame, and can be flexibly configurated. it is the necessary equipment in the opitcal access network.
2.Feature
1. 19" Standard rack mount
2. Material: SPCC cold rolled steel
3. Designed by full modulization:
A. Unit body have the funsion of optical fiber fusion, tray storing and distribution
B. the integrated fusion and distribution tray can be singly taken out to meet the demands for operation.
4. Optical cable, pigtail fiber and patch cords can be clearly managed,
5. Easy for installation of inlay,convenient to expand capacity,obliquity of adapter is 30 degree.
6. Ensure the bend radius of patch cord and avoid laser burning eyes.
7. FC, SC port is available for the integrated fusion and distribution tray
8. Two sides accommodate cable entry and exit
3.Specification
1. Under the general air pressure, 500VDC,insulation resistance≥1000MΩ;
2. The high voltage protection can undertake 3000VDC,no spark-through and flashover within 1 minutes.
3. Technical and quality grade reaches the ISO/IEC11801 requirement.
4. Working temperature-20°C~+55°C;
5. Working humidity≤95% (30°C);
6. Working atmospheric pressure 70~106KPa
4.Product list
Capacity |
Dimension(mm) |
Weight(kg) |
12 port |
430 x 300 x 35 |
3KG |
24 port |
430 x 300 x 70 |
5KG |
48 port |
430 x 300 x 140 |
7KG |
72 port |
430 x 300 x 200 |
10KG |
96 port |
430 x 300 x 250 |
13kg |
