10/100/1000M Ethenet 8 port SFP fiber switch
- 20000 Set / Sets per Month
- ports in Shenzhen
- Credit Card
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | TINCAM | Model Number: | TBC-Mc3714e-D20-LC |
Product Description
10/100/1000M Ethenet 8 port SFP fiber switch
DESCRIPTION
TBC-3742 Gigabit Ethernet Switch with
two10/100/1000M UTP port sand four fiber ports
Or four 1000M SFP sockets(The end users can use
different SFP Module according to his requirement,for example:1000Base-T,1000Base-SX,1000Base-LX etc.
The product is possessed of stable performance,excellent quality and reasonable price because of adopting latest IC from USA and high quality of transceivers.It is applicable to use in small patterns of Optical Fiber Ethernet.
FEATURES
n 2 RJ45 ports and 4 LC fiber ports or 4 SFP sockets,
n It can convert Optical Electric Ethernet signals between 10/100/1000M UTP ports and 1000M optical fiber ports and switch Ethernet signals between port and port.
n Auto negotiation function supports UTP ports to auto 10/100/1000M and Full Duplex/Half Duplex.
n Broadcast storm protection
n Supports VLAN and QoS
n Supports STP,IPV6,IPV4
n Supports the max1536 bytes frame
n Small power consumption(3W),low heat,good stability
TECHINCAL SPECIFICATIONS
Standard Protocol | IEEE 802.3 10Base-T | |||
IEEE 802.3u 100Base-TX | ||||
IEEE 802.3ab 1000Base-T | ||||
IEEE802.3z 1000Base-SX/LX | ||||
Band Width | RJ 45 Port: 10/100/1000Mbps | Optical Port: 1.25Gbps | ||
Operation Mode | Full /Half duplex mode | |||
Connectors | UTP: 2 RJ-45 | Fiber connector: SC/LC | ||
Operation Mode | Full /Half duplex mode | |||
Power Supply | External | AC110-250V/50Hz | ||
DC 5V 2A | ||||
Power Consumption | ≤5W | |||
Environmental Parameters | Work Temperature | 0℃~50℃ (32 °F ~ 122 °F ) | ||
Storage Temperature | -40℃~70℃ (-40 °F ~ 158 °F ) | |||
Humidity | 5%~90% non-condensing | |||
TP Cable | Cat5 UTP cable (the max distance up to 100m) | |||
Fiber Cable | 8. 3/125, 8. 7/125, 9/125, 10/125μm(the max distance up to 20 -120km) | |||
50/125, 62. 5/125μm(the max distance up to 2km or 5km) | ||||
MTBF (Hours) | >50000 | |||
Dimensions(mm) | External power supply | 155mm*90mm*27mm | ||
Gross Weight | External power supply | 0.5kg | ||
Emission/Safety | FCC Part 15 , Class A, RoHS and CE Mark |
TBC-3742-D20-SC | 2 X10/100/1000M with 4 X1000M fiber ports dual fiber SC 20KM |
TBC-3742-S20-SFP | 2 X10/100/1000M with 4 X1000M fiber ports dual fiber LC 20KM |
TBC-3742-D20-SFP | 2 X10/100/1000M with 4 X 1000M fiber ports 4 SFP sockets 20KM |
