KUNBO 100-10000L Industrial Medicine Drink Food Jacket Mixing Tanks Mixer
US$ 600 - 7,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
KUNBO
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KUNBO Jacket Cooking Kettle Cooker With AgitatorUS$ 600 - 3,000MOQ: 1 Set -
KUNBO 1000L Stainless Steel Food Beverage Mixer Mixing TankUS$ 600 - 7,000MOQ: 1 Set
-
KUNBO Food Steam Jacketed Jacket Brew Mixing Cooking KettleUS$ 600 - 3,000MOQ: 1 Set
-
KUNBO Stainless Steel Jacket Steam Jacketed Tank Mash KettleUS$ 600 - 7,000MOQ: 1 Set
-
KUNBO Stainless Steel Double Jacket Tank Steam Jacketed KettleUS$ 600 - 7,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
KUNBO
Model Number
Fermenter-007
Processing Types
Carbonated Beverage
Voltage
380V, 50HZ
Power(W)
According to customers
Dimension(L*W*H)
Different volume different sizes
Weight
Different Design, Different Weight
Certification
B&V,CE
Warranty
12 months against B/L date for beer brewing equipment
After-sales Service Provided
Overseas service center available
100-10000L Industrial Medicine Drink Food Jacket Mixing Tanks Mixer
| Mixing Tank with Side Mixer | |
| Company introducation | We Kuangbo is a production enterprise of pharmaceutical, dairy, food and beer-making equipment, alongside biological engineering, chemical containers, and bespoke products. Our products are widely used in beer production, pharmaceuticals, beverage industries, biotechnology and other fields. |
| Usage | It is widely used for liquid-liquid mixing and liquid storing. It applies in food, beverage industry, phatmacy and chemical industry. |
| Material | Stainless Steel 304 or 316L |
| Technology & Design | 1. Made of three-layer with whole jacket and insulation with PU. |
| 2. It is heated by electric element, there is a hopper at the side for adding water into jacket. | |
| 3. Dish top and bottom, cylinder body. Top is connected by flange for easy open. | |
| 4. As to polish, interior layer and exterior layer all adopts 3A mirror polish. | |
| 5. As to transition of interior, we will adopt arc to make sure that there is no dead corner of sanitation. | |
| 6. The speed of impeller is range from 0 RPM to 300RPM. | |
| 7. There is a control panel together with the tank for controlling impeller speed, motor on-off, conductive level switch controlling, electric valve controlling, electric element on-off. | |
| 8. Legs with wheel or with adjustable feet is up to you. | |
| Configuration | Outlet, Siemens motor, spraying ball, manhole, temperature probe, motor, impeller, water inlet and outlet, legs (wheel or adjustable feet ) |
| Volume | 100-10000L |
| Advantage | 1.We also can design the configuration details as your requirements |
| 2.Competitive price and also higher quality tank. | |
| Minimum order | One unit |
| Payment term | T/T or L/C |
| Package | Export standard package |
| Market | At home and abroad |
| Mixing Tank Technical Parameter | ||||||
| Working Volume (L) | Dimension of Tank (D*H) mm | Total Height (mm) | Dia of inlet & outlet (mm) | PU Insulation (mm) | Motor Power (kw) | Mixing Speed (r/min) |
| 500 | 800*800 | 1700 | 38 | 50 | 0.75 | ABB/Siemens 35-150 RPM |
| 800 | 900*1200 | 2000 | 38 | 50 | 0.75 | |
| 1000 | 1100*1000 | 2400 | 38 | 50 | 1.1 | |
| 2000 | 1200*1500 | 3000 | 38 | 50 | 1.5 | |
| 3000 | 1450*1500 | 3150 | 51 | 50 | 1.5 | |
| 4000 | 1550*1800 | 3500 | 51 | 50 | 2.2 | |
| 5000 | 1600*2000 | 3850 | 51 | 50 | 2.2 | |
| 6000 | 1700*2200 | 4000 | 51 | 50 | 3 | |
FAQ:
1. Can your brewing equipment make both lager and ale?
A: Yes, our beer brewing equipment can make both lager and ale.
2. How to achieve temperature control?
A: The PLC or digital dispalyer could control the temperature by connecting with the PT 100 sensor.
The brewing tanks with rock wool to keep warm, the fermenters and bright beer tank with PU as
cooling jacket to keep cool.
3. Is it possible to supply installation in our country?
A: Yes, we could supply our clients over sea service and direct the installation and brewing.
