CCS Approved Zibo Chinese Marine Diesel Engine for Propulsion

Name: CCS Approved Zibo Chinese Marine Diesel Engine for Propulsion
Brand: ZIBO
SKU: 103726479

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Usage:

Other, Boat, for propulsion

Fuel:

Diesel

Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Other, Boat, for propulsion

Fuel Diesel

Stroke 4 Stroke

Cylinder Multi-cylinder

Cold Style Other, Water-cooled

Start Electric Start

Place of Origin Shandong, China

Brand Name ZIBO

Model Number ZB170ZLD

Dimension(L*W*H) 3080*1440*2053

Weight 4800

Certification CCS

Warranty one year warranty

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Chinese marine diesel engine
1.One year warranty
2. speed:1000 rpm
3.CCS certificate
4.Coupled with gear box for propulsion

Chinese marine diesel engine specification:

1.The main data of left engine is same with right engine in every model engine.

2.Rotation direction of crankshaft: The left engine resolves right, the right engine resolves right to look from the flywheel

side to the free side, to turn right is clockwise.

3.The left engine resolves left, the right engine resolves left to look from the flywheel side to the free side, to turn left is

counter-clockwise.

4.Starting method: Air motor or electric motor.

Marine engine main parameter:

Engine Model	Z6170ZLD-8
Number of Cylinders	8 cylinders in line
Cycle	4 stroke
Aspiration	Turbocharged and after cooled
Bore×Stroke	170 x200 mm
Prime Power/Speed	441kw/1000rpm
Speed Governor	electrical
Cooling System	By heat exchanger
Fuel Consumption at 100% Load	198 g/kw.h
Starter Motor	DC24V,
