New Products Windshield UHF RFID Tag for automated toll road
Brief Introduction:
| Item | Description | Remarks | |
| Manufacture / Chip | Alien/Higgs3 | ||
| Base Material | PET | ||
| Antenna | Al(9μm)+PET(50μm) |
||
| Protocol | ISO/IEC 18000-6C |
||
| Memory | EPC | 96Bits | Read & Write |
| TID | 32Bits | Read Only | |
|
Unique TID Field |
64Bits | Read Only | |
Password Field |
32Bits 32Bits |
Read & Write | |
| User Area | 512Bits | Read & Write | |
| Frequency | 860~960MHz | ||
| Operating Mode | Passive | ||
| IC Life | 100,000 Programming cycles, |
||
| ESD Voltage Immunity | 2000V | Human being mode(HBM) | |
Specifications:
- Model : rfid tag
- Frequency: 860~960MHz
- Small size: Smallest to be 12X19X0.56mm, customized
- Printings :Offset printing, silk-screen printing
- Working temperature: -20°C ~ +50°C
- Read range: 15cm - 11m, depend on the reader and tag antenna size
- Outstanding : easy to carry, waterproof, shockproof, thermo stability
Brief Introduction:
Dry Inlay:
They are described as "dry" is because when they are attached to the label without the use of an adhesive.
Wet Inlay:
they are described as “wet” due to their adhesive backing, so they are essentially industrial RFIDstickers.
Componets:
The RFID inlay consists of two components. An integrated circuit or microchip that stores personal identifying information attaches to a small coil of aluminum, copper or silver wires called the antenna, which transmits and receives radio frequency signals. The microchip and antenna are then placed on a label, and the entire unit is encased in plastic.
How it works ?
Data from the microchip passes to the RFID tag's antenna, where it is read by the antenna of an RFID reader and passed onto a host computer system for archival purposes, processing or analysis.
Typical application--Advertising & Promotion:
1. Promotional items equipped with an NFC link to advertise e.g. websites or online shops instantly connect the consumer to the target site.
2. NFC tags can also have cross-media functionality: when attached to posters, magazines and the like, access to exclusive internet content is granted and consumer interaction such as purchase of tickets or download of music is initiated.
Other application:
- Access control & time attendance
- E-payment
- Mobile payment
- Loyalty & Membership Management
- Supply Chain Management
- Staff Identification
- Ticketing
Our Advantages:
*Best Service
*Best Quality
*Fast Delivery
*Competitive Price
*Complete machine equipment
Contact us:
| Amanda Yang |
QR code
|
Shenzhen Z Fine Smart Card Co., Ltd |
|
| T:86-0755-29473006-8009 | |
| Phone: 86-18938309828 | |
| Skype: zfinecard009 | |
| Website: |
Product Display:
