Specifications
Deutz Diesel Genset-Air cooledEngine model:F8L413F
Alternator model:MP-100-4
Air cooled Deutz diesel genset
Generator Model |
JG100GF |
Prime Power |
100KW/125KVA |
Standby Power |
110KW/138KVA |
Voltage |
400V |
Frequency |
50HZ/1500 rpm |
Power factor |
0.8 |
Dimensions |
1900x800x1150mm |
Weight |
800kg |
Relative Humidity |
60% |
Overload |
10% MAX. |
Engine |
Standby rating |
Prime rating |
Manufacturer |
Deutz |
|
Model |
F8L413F |
|
Configuration |
4 cycle,8 cylinder in V |
|
Cooling system |
Air-cooled |
|
Output |
113KW/142KVA |
103KW/129KVA |
Bore and Stroke |
125×130mm |
|
Rated Speed |
1500 rpm |
|
Displacement |
12.7L |
|
Compression ratio |
18.0:1 |
|
Fuel Consumption |
216g/kw.h |
|
Alternator |
Standby rating |
Prime rating |
Manufacturer |
Marathon |
|
Model |
MP-100-4 |
|
Capacity |
110KW/138KVA |
100KW/125KVA |
Voltage |
400V |
|
Frequency & speed |
50HZ / 1500rpm |
|
Power factor |
0.8 |
|
Altitude |
≤1000m |
|
Exciter type |
Brushless,self-exciting |
|
Phase and wire |
Single phase |
|
Protection Grade |
IP23 |
|
Insulation Class |
H/H |
|
Voltage Reguation Steady State |
≤1% |
|
Rotation(seen from flywheel end) |
clockwise |
|
