Help CenterOn Promotion Generator Chinese Engine 50Hz Small Diesel Marine Generator
Related Products
-
Factory Direct Sale 40KW ShangChai Marine Diesel GeneratorNegotiableMOQ: 1 Set -
100kw Marine Diesel Generator From Chinese Manufactory With Famous Brand for Hot SaleUS$ 15,000 - 18,000MOQ: 1 Set
-
HOT SALE 100KW MWM Marine Engine Generator With CCS, ABS, BV, DNVUS$ 8,000 - 10,000MOQ: 1 Set
-
120KW MWM Marine Engine Diesel Generator With CCS, ABS, BV, DNVNegotiableMOQ: 1 Set
-
150KW MWM Marine Gensets With CCSUS$ 15,000 - 25,000MOQ: 1 Set
Specifications
small diesel marine generators1.CCS,ZY certificate
2.One year warranty
3.maintenance-free battery
4.with silencer
1. Small diesel marine generator specification :
1) Coupled with Changqing diesel engine and Stamford Or Marathon alternator
2) 24V DC start motor and storage battery
3) Brushless, Self-excited, IP23, insulation class H alternator
4) All generator sets are gone through rigorous testing before being released to the
market place, including 50% load, 75% load, 100% load , 110% load and all protection
function (overspeed stop, high water temperature, low oil pressure, battery charging fail, emergency stop
1.Main technical data of 10kw marine generator | ||
1.1 |
Model |
JGC10GF |
1.2 |
Prime power |
10KW/12.5KVA |
1.3 |
Prime voltage |
230/400V |
1.4 |
Speed |
1500 rpm |
1.5 |
Weight |
780kg |
1.6 |
Overall dimension |
1670×850×1270mm (just for reference) |
2.Main technical data of cummins engine | ||
Cummins engine, 4 stroke. DC start. | ||
2.1 |
Brand |
Changqing |
2.2 |
Model |
4100D |
2.3 |
Prime power |
26.5KW |
2.4 |
Governor type |
Electronic |
2.5 |
Configuration |
4 cycle , 4 cylinder in line |
2.6 |
Air Intake System |
Natural Aspirate |
2.7 |
Bore/Stroke |
102×120mm |
2.8 |
Displacement |
3.9 L |
2.9 |
Starting method |
Electric |
2.10 |
Compression ratio |
16.5:1 |
2.11 |
Fuel consumption |
228g/kw.h |
3. Main technical data of alternator | ||
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation. | ||
3.1 |
Brand |
MARATHON |
3.2 |
Model |
GM-12-4 |
3.3 |
Prime power |
12KW/15KVA |
3.4 |
Configuration |
Brushless , self-exciting |
3.5 |
Prime voltage |
230V/400V |
3.6 |
Frequency |
50 HZ |
3.7 |
Power factor |
0.8(lagging) |
3.8 |
Phase/wire |
3 phase 3 wires |
3.9 |
Isolation |
H |
