Specifications
1.water cooled marine diesel generator2.global service for 12 month
3.ISO,CE,BV,CCS certificate
4.EIAPP(Nox) certificate
1. water cooled marine diesel generator specifications:
Fengde Cummins series marine generator have features of compact structure, large power , low oil consumption , low discharge, low noise, reliable performances, and long services life .Its professional service networks are spread across the country and world , which can provide 24 hours after service and assure the supplying of accessories in time .
Feature:
Marine generator can use for Marine generator,
Marine emergency generator or Harbor generator
We use the marine synchronouse Alternator with the brands of Stamford , Marathon and Simens marine Alternator etc. Also can be supplied at the request of customers.
Parallel connection: Two and more normal marine generating sets can transfer loading without stoping , and can realize parallel.
Protection function :Thare are over-limit alarming for speed , oil pressure, cooling water temperature and oil temperature.
Can provide CCS, BV , ABS,GL,RS, DNV classification certificate.
We are the top VIP supplier on Alibaba,
authorized by famous certification authority-BV ( Bureau Veritas ).
2. Diesel Generator Technical Data:
150KW Marine diesel gensets Technical specification
1.Main technical data of genset | ||
1.1 |
Model |
CCFJ150J |
1.2 |
Prime power |
150KW |
1.3 |
Prime voltage |
230/400V |
1.4 |
Speed |
1800 rpm |
1.5 |
Weight |
2900kg |
1.6 |
Overall dimension |
2550×980×2250mm (just for reference) |
2.Main technical data of engine | ||
Cummins engine, 4 stroke. DC start. Come with sea water pump, heater exchanger and expansion water tank, open-cycle cooling. | ||
2.1 |
Brand |
CUMMINS |
2.2 |
Model |
6LTAA8.9-GM200 |
2.3 |
Prime power |
200KW |
2.4 |
Governor type |
Electronic |
2.5 |
Configuration |
4 cycle , 6 cylinder in line |
2.6 |
Cooling method |
By heater exchanger |
2.7 |
Bore/Stroke |
114×145 mm |
2.8 |
Displacement |
8.9 L |
2.9 |
Starting method |
Electric |
2.10 |
Fuel consumption |
212g/kw.h |
3. Main technical data of alternator | ||
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation. | ||
3.1 |
Brand |
MARATHON |
3.2 |
Model |
MP-H-150-4 |
3.3 |
Prime power |
150KW |
3.4 |
Configuration |
Brushless , self-exciting |
3.5 |
Prime voltage |
230V/400V |
3.6 |
Frequency |
50 HZ |
3.7 |
Power factor |
0.8(lagging) |
3.8 |
Phase/wire |
3 phase 4 wires |
3.9 |
Isolation |
H |
3.Warranty
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4. Document
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
