Specifications
1.Material:PVC,PET;2.Size:85.5*54*0.76mm
3.Frequency:125KHz or13.56MHz or 915MHz
4. Professional production inlay.
125KHZ proximity rfid card for time attendance :
Smart cards are the size of a conventional credit or debit card with an integrated circuit chip that contains a memory,
or a memory plus a microprocessor. Memory only chips contain the operating program,
and up to 64 K bytes of reusable memory. Cards with a microprocessor are used for added
security when handling sensitive information.
Specifications:
1.Material:PVC,PET;
2.Size:85.5*54*0.8mm,customized available.
3.Frequency:125KHz or13.56MHz or 915MHz
4. Professional production inlay,High quality
5.automatic ultrasonic embedding process
6.Surface Finish:Glossy or matte,film Lamination
our advantages:
*Complete machine equipment
*Best Quality
*Fast Delivery
*Competitive Price
*Best Service
More details :
Product name |
PVC smart card |
Material |
PVC or PET |
Size |
54*85.5*0.76mm |
Frequency |
13.56MHz |
Communication Protocol |
ISO 14443A |
Work temperature |
-15°C~+55°C |
Packaging technology |
Ultrasonic automatic winding and Automatic Welding |
Surface treatment technology |
Glossy or matte |
Surface optional design |
Four-color offset printing, magnetic stripe, signature strips, marking,laser code,Convex code,Punch,Bronzing,hot silver, plus security, embossed oil, Gold-plated at the end,Silvering the end of |
Spare number |
1.0‰ |
Weight of per card: |
0.6g |
Packing |
200pcs/box,2000pcs/carton;carton size:50*24*15cm |
Available Chips:
Chip name |
Standard compliance |
EEPROM /bit |
Mode |
Anticollision |
S50 |
ISO 14443A |
8*1024 |
R/W |
Y |
S70 |
ISO 14443A |
32*1024 |
R/W |
Y |
Ultralight |
ISO 14443A |
512 |
R/W |
Y |
DESFire |
ISO 14443A |
32*1024 |
R/W |
Y |
SR176 |
ISO 14443B |
176 |
R/W |
Y |
ICODE SLI |
ISO 15693 |
1024 |
R/W |
Y |
Legic MIM 256 |
Legic RF Standard |
8*256 |
R/W |
Y |
Ti2048 |
ISO 15693 |
2048 |
R/W |
Y |
Applications:
Public Transport :subway tickets, bus RFID ticket
Access Control: payment membership card, time attendance, game ticket , Logistics,
hotel management, transportation, library and campus, Parking lot system and Consuming system,
anti-fake label, warehouse management, production line
Access Control , Cashless Vending, Loyalty & Discount Cards Leisure card,Toll Card,
Student/Campus Card/School Card, Identity Card, etc
ZFine make things easy:
1.your any inquiry will have our highest attention ,and replied within 24 hours.
2.we have decades R&D experience in smart card field,you can rest assured that we can
provide the superior quality cards with competitive price .
3.do not familiar with the technology ?
Don't worry ! our technology team work for you ,and help you to achieve your projection !
4.first time cooperate with us ?
free sample is available ! you can check the quality .
still worry ? welcome visit our factory !
