Help CenterCE RoHS Ultra-thin Slim High Efficiency Constant Voltage Single Output AC DC 200W 24v 8.5a Led Driver
Related Products
-
Good Price Single Output Constant Voltage 300w 220v Input 36v dc Power SupplyUS$ 8 - 15MOQ: 1 Set -
Constant Voltage ac dc 150w 24v Switching Power Supply UnitUS$ 10 - 16MOQ: 1 Set
-
CE RoHS Approved High Efficiency Single Output Constant Voltage ac dc 12v Smps 400wUS$ 3 - 15MOQ: 1 Set
-
SSMPS Single Output Constant Voltage ac to dc 60W 12v Converter With CE RoHSUS$ 4 - 8MOQ: 1 Set
-
Constant Voltage 60w 12v dc Input Atx Power Supply With CE RoHSUS$ 6 - 12MOQ: 1 Set
Specifications
LED driver 24v 8.5a 200wCE RoHS slim high quality
Input voltage: 100~240VAC
DC output: can be customized
Constant voltage
LED driver description:
Product name:HBC-200W-24V LED driver
Rated power: 200W
Output voltage: DC24V
Ultra-thin,only 30mm
Efficiency:88%
Ripple & Noise (max.): 150mVp-p
Over load protection: 110~115% rated output power
Over voltage protection: 26.4~32.4V
Over temperature protection: 100°C±5°
Business type: Manufacturer/Factory
Trade Mark: HPower
Certificates: CE, RoHS, CCC
Warranty:2 years
LED driver features:
v Universal AC input/Full range
v Protection: Short circuit/Overload /Over Voltage/Over Temperature
v Cooling by free air convection
v Bult-in constant current limiting circuit
v LED indicator for power on
v 8 hrs and 100% full load bult-in test
LED driver details:
200w Series, include output 5v, 12v, 15v, 24v and 36v.
| HBC-200W-5V | HBC-200W-12V | HBC-200W-15V | HBC-200W-24V | HBC-200W-36V | |
| DC Voltage | 5V | 12V | 15V | 24V | 36V |
| Rated Current | 40A | 17A | 13A | 8.5A | 5.5A |
| Current Range | 0~40A | 0~17A | 0~13A | 0~8.5A | 0~5.5A |
| Rated Power | 200W | 204W | 195W | 204W | 198W |
| Ripple & Noise (max.) | 100mVp-p | 100mVp-p | 150mVp-p | 150mVp-p | 150mVp-p |
| Voltage Adj. Range | 4.75~5.5V | 11.4~13.2V | 14.3~16.5V | 22.8~26.4V | 34.2~39.6V |
| Voltage Tolerance | ±2.0% | ±2.0% | ±2.0% | ±1.0% | ±1.0% |
| Line Regulation | ±1.0% | ±1.0% | ±1.0% | ±0.5% | ±0.5% |
| Load Regulation | ±5.0% | ±5.0% | ±5.0% | ±5.0% | ±5.0% |
| Setup,Rise time | 600ms,30ms at full load | ||||
| Hold Up Time(Typ.) | 13ms at full load | ||||
| Voltage Range | 90~132VAC/180~264VAC | ||||
| Frequency Range | 47~63HZ | ||||
| Efficiency(Typ.) | 83% | 86% | 85% | 88% | 90% |
| AC Current (Typ.) | 5A/115VAC 3A/230VAC | ||||
| Inrush Current (Typ.) | 30A/115VAC 50A/230VAC | ||||
| Leakage Current | <2mA / 240VAC | ||||
| Over Load | 110~115% rated output power | ||||
| Protection type: Shut down O/P,re-power on to recover | |||||
| Over Voltage | 5.5~6.75V | 13.2~16.2V | 16.5~20.25V | 26.4~32.4V | 39.6~48.6V |
| Protection type: Shut down O/P,re-power on to recover | |||||
| Over Temperature | 100°C±5°C(5V~12V); 105°C±5°C(15V~36V); TSW1 detect on main power transformer for others | ||||
| Protection type: Shut down O/P,recovers automatically after temperature goes down | |||||
| Working Temperature | -20~+40°C | ||||
| Working Humidity | 20~90% RH Non-condensing | ||||
| Storage temp.& humidity | -20~+85°C, 10~95%RH | ||||
| Temp. coefficient | ±0.03%/°C (0~50°C) | ||||
| Vibration | 10 ~ 500Hz, 3G 10min./1 cycle,60min.each along X,Y,Z axes | ||||
| Safety Standards | UL60950-1 approved | ||||
| Withstand Voltage | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||||
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH | ||||
| MTBF | 10000hrs MIL-HDBK-217F (25°C) | ||||
| Dimension | 190*85*30mm (L*W*H) | ||||
| Packing | 0.56Kg; 52pcs/31.4Kg/1.79CUFT | ||||
| 1. All parameters NOT specially mentioned are measured at 220VAC input, rated load and 25°C of ambient temperature. | |||||
| 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 10uf parallel capacitor. | |||||
| 3. Tolerance: includes set up tolerance, line regulation and load regulation. | |||||
| 4. Derating may be needed under low input voltages. | |||||
LED driver structural drawing(Unit::mm):
LED driver derating curve:
LED driver applications:
1. LED display, led strip, nixie tube, street light, lamp;
2. Electrical equipment, Instrumentation;
3. Digital and electronic products;
4. LCD, LED, CCTV camera;
5. Building lighting decoration;
6. Communications and security products.
Our led driver show room:
Our led driver workshop:
LED driver packing & delivery
Lead time: 7-15 days
Delivery method:
ü Express service: FedEx/DHL/UPS/TNT/EMS
ü Air transportation: factory to airport
ü Ocean shipping: factory to port
