Specifications
100% Copper Wire ST Single Phase AC Alternator 10kw1.100% Copper wire
2.Strong base frame
3.Low price
4.Full Power
100% Copper Wire ST Single Phase AC Alternator 10kw
AC Alternator
The generators are of drip-poof with rotary field type and with the adoption of harmonic excitation system, that allow your easy
The generators are to be used in town,the countryside, worksites, mountain and pasture lands as a electric power source for lighting purpose,It can also be used as a reserved power source for emergent case.The generators are of drip-poof with rotary field type and with the adoption of harmonic excitation system, that allow your easy operation and simple maintenance.
The generators are of three-phase four-wire type, making use of atar connection with neutral point. The rated line voltage is 400V. phase voltage 230V. frequency 50Hz. power factor 0.8(lag). It can provide 60Hz and the other voltages generator according to necessary. They can be coupled with a prime mover directly or through V-belt making right or reverse continuous rotation at the rated speed. when the revolution slip of prime mover is 3% and load varies in the range of 0 100% cos F 1.0 0.8 they give food constant voltage. After sudden change (increase or decrease)of load. the generators will soon return to their normal working state. without any starting devices the generator can directly start an unloaded squirrel cage induction motor.
Operating conditions
Under the following environment,the generator could run continuously:
1.Altitude:not exceed 1000m
2.Ambient temperature:-15°C-40°C
3.Relative air humidity:≤90%
Operating Conditions:
Under the following environment, The generator could be continuous and rated running:
Above sea level: Not exceed 1000m
Cooling air temperature: 258~313K(-15 oC ~ 40 oC)
Relative air damping: not exceed 90%
Guaranty:
Guarantee for one year or 1000 hours (whichever comes first) from ex-factory date. During the guarantee period, our Boomaster will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials, except the damage caused by customer's incorrect manmade operation. After expiration, our company will provides cost spare parts maintenance for genset.
