20w all in one integrated solar street lights
Technical Parameters
Model |
Led Brand |
Led Power |
Luminous Flux |
Power of solar panel |
Power of Lithium battery |
Control Model |
MSL-A15W |
PHILIPS/SUMSUN |
15W |
1575LM |
45W |
15AH |
INFRARED INDUCTION |
MSL-A20W |
PHILIPS/SUMSUN |
20W |
2100LM |
45W |
20AH |
INFRARED INDUCTION |
MSL-A25W |
PHILIPS/SUMSUN |
25W |
2625LM |
70W |
25AH |
INFRARED INDUCTION |
MSL-A30W |
PHILIPS/SUMSUN |
30W |
3150LM |
70W |
30AH |
INFRARED INDUCTION |
Illuminance Diagram
|
Power |
Illminance Data(LUX) |
Recommended the height of pole |
|||||
3M |
4M |
5M |
6M |
7M |
8M |
||
15W |
28 |
25 |
20 |
16 |
12 |
8 |
3-5M |
20W |
35 |
31 |
25 |
19 |
15 |
11 |
4-6M |
25W |
39 |
35 |
29 |
23 |
18 |
14 |
5-7M |
30W |
44 |
39 |
34 |
27 |
23 |
18 |
6-8M |
Packing Details
Model |
Product Size |
Packing Size |
Net Weight |
Gross Weight |
15W |
900MM*430MM*55MM |
950MM*530MM*75MM |
12.6KG |
13.2KG |
320MM*300MM*200MM |
330MM*310MM*210MM |
2.1KG |
2.3KG |
|
20W |
900MM*430MM*55MM |
950MM*530MM*75MM |
13.2KG |
13.6KG |
320MM*300MM*200MM |
330MM*310MM*210MM |
2.8KG |
3KG |
|
25W |
1250MM*430MM*55MM |
1430MM*530MM*75MM |
15.6KG |
16.2KG |
320MM*300MM*200MM |
330MM*310MM*210MM |
3.6KG |
3.8KG |
|
30W |
1250MM*430MM*55MM |
1430MM*530MM*75MM |
16.2KG |
16.8KG |
320MM*300MM*200MM |
330MM*310MM*210MM |
4.2KG |
4.4KG |
