Product Details
| Place of Origin | Jiangsu, China | Brand Name | Banda | |
| Model Number | BD-G01 | Usage | Other, Freight Elevator | |
| Drive Type | AC, Other, AC, VVVF | Elevator Type | Goods Elevators |
Product Description
Freight elevator
1.Accurate leveling
2.Sturdy and durable
3.Large door width
4.Superior speed governor
Freight elevator Landing door series
It is equipped with multiple opening modes to satisfy various door opening breadths.
__________________________________________________________________________________
Freight elevator Properties
Freight elevator Energy-saving
__________________________________________________________________________________
Variable frequency goods elevator applies VVVF voltage and speed regulative technology to vigorously reduce the lift running power loss and power supply capacity, it saves nearly 20% of energy comparing with the traditional AC double-speed traction.
Freight elevator Superior speed governor
__________________________________________________________________________________
VVVF speed governor and the unique curve running condition of variable frequency goods elevator can smoothly adjust the elevator speed. It largely improves the coziness, leveling precision and running noise of lift operation.
Freight elevator Space-saving
__________________________________________________________________________________
The permanent magnet synchronous gearless traction machine has characteristics like light weight, compact structure, small size etc. That saves space required by freight elevator. It is convenient for the shaft arrangement of the machine room less freight elevator.
Freight elevator Large load
__________________________________________________________________________________
It improves the rated load of goods elevator from 1600kg to 3000kg, which meet the clients’ requirement.
Within 35 days after receiving the deposit.
Freight elevator construction parameters sheet __________________________________________________________________________________
| Load (kg) | Speed (m/s) | Door opening size (mm) | Car size (mm) | Hoistway size (mm) | Machine room size (mm) | Top floor height (mm) | Pit depth (mm) | Maxi travelling height (mm) | ||||
| C.W | C.D | H.W | H.D | MR.W | MR.D | MR.H | ||||||
| 1000 | 0.50 | 1100 | 1400 | 1700 | 2350 | 2200 | 2700 | 3500 | 2500 | 4300 | 1500 | 30 |
| 2000 | 0.50 | 1500 | 1800 | 2300 | 2750 | 2800 | 2700 | 4000 | 2500 | 4300 | 1500 | 30 |
| 3000 | 0.50 | 1800 | 2000 | 2900 | 3300 | 3400 | 3300 | 4500 | 2500 | 4500 | 1600 | 30 |
| 5000 | 0.25/0.50 | 2200 | 2500 | 3500 | 3900 | 4000 | 3900 | 4000 | 2800 | 5100 | 1700 | 15/30 |
MRL freight elevator construction parameters sheet
__________________________________________________________________________________
| Load (kg) | Speed (m/s) | Net size of door (mm) | Net size of car (mm) | Hoistway size (mm) | Traction ratio | ||||
| 2P side opening | 4P side opening | C.W | C.D | H.W×H.D | HR.H | P.H | |||
| 1000 | 0.50 | - | 1200×2100 | 1500 | 1600 | 2500×2100 | 4500 | 1500 | 2:1 |
| 2000 | 0.50 | - | 1500×2100 | 1500 | 2750 | 2800×3250 | 4500 | 1500 | 4:1 |
| 3000 | 0.50 | - | 1800×2100 | 2000 | 2000 | 3350×3400 | 4800 | 1700 | 4:1 |
