BGO1401series
Features :
| Model | BGO1401-10 | BGO1401-20 | BGO1401-30 | BGO1401-50 | BGO1401-60 |
| Electric supply | 220-240V ~50Hz | 220-240V ~50Hz | 220-240V ~50Hz | 220-240V ~50Hz | 220-240V ~50Hz |
| Capacity | 10KW | 20KW | 30KW | 50KW | 60KW |
| 34120 Btu/h | 68240 Btu/h | 102360 Btu/h | 170600 Btu/h | 204720 Btu/h | |
| 8600 Kcal/h | 17200 Kcal/h | 25800 Kcal/h | 43000 Kcal/h | 51600 Kcal/h | |
| Motor power | 160 W | 160 W | 180 W | 180 W | 340 W |
| Air Output | 650 m³/h | 650 m³/h | 850 m³/h | 1100 m³/h | 1100 m³/h |
| Fuel consumption | 0.8 kg/h | 1.6 kg/h | 2.4 kg/h | 4.0 kg/h | 4.8 kg/h |
| Tank capacity | 12 L | 12 L | 19 L | 38 L | 56 L |
| Product Meast | 660x260x380mm | 660x260x380mm | 830x410x540mm | 860x456x600mm | 1050x490x615mm |
| Packing Meast | 690x325x410mm | 690x325x410mm | 770x370x490mm | 880x395x500mm | 1010x450x570mm |
| N.W. | 10.3 kgs | 10.3 kgs | 16.6 kgs | 22 kgs | 27.5 kgs |
| G.W. | 12.4 kgs | 12.4 kgs | 19.5 kgs | 25 kgs | 30.5 kgs |
| Qty/20' | 300 pcs | 300 pcs | 204 pcs | 160 pcs | 108 pcs |
| Qty/40' | 640 pcs | 640 pcs | 420 pcs | 330 pcs | 195 pcs |
| Qty/40'HQ | 740 pcs | 740 pcs | 475 pcs | 388 pcs | 260 pcs |
Industrial diesel heater
1.Unique and tough design
2. Function on diesel oil or kerosene
3. Stainless steel combustion chamber with fan cooling
4. Durable extemal powder coating
5. With flame sensor
6. If no oil , heater will cut off the power
7. Fixed Oil display
8.Cut-off protection,re-plugged in will not work automatically
9.Low pressure atomization,combustion completely
10. Easy maintenance
11. Built-in thermostat with digital display
12. Ideal for heating warehouses,factories and workshops etc.
Certificates:
CE / GS / LVD / EMC / RoHS approved .
Where to use
* Construction Sites * Factories * Barns
* Agriculture * Sports Events * Utility/Farm Buildings
Introduction:
* Company history: established in 1999. professional manufacturer specialized in heaters.
* Industrial fan heater, industrial diesel heater, gas forced heater,radiator heater,quartz heater etc.
*Main markets: Germany, Denmark, Norway, Sweden, Finland, UK, France,Russia, Australia, America and Asia etc.
* Employees: 320-400
* Production capacity: 6+ lines , 800,000 pcs/ year,
* Quality management system: ISO 9001
Quality control system:
IQC (Incoming Quality Control)
IPQC (In Process Quality Control)
PQC (Process Quality Control)
FQC (Final Quality Control)
OQC (Out-going Quality Control)
