VM1370 3 axis cnc machine center price

FOB Price

USD $68,500 - $77,500 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Place of Origin:	Liaoning, China	Brand Name:	R&C
Model Number:	VM1370	Type:	Vertical	CNC or Not:	CNC
Voltage:	380V	Power(W):	7.5-11KW	Dimension(LWH):	TALK MORE
Weight:	13	Certification:	CE ISO BV	Warranty:	1 YEAR
After-sales Service Provided:	Engineers available to service machinery overseas

VM1370 3 axis cnc machine center price

IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C

SPECIFICATION

tem		VM1370	unit
Travel	X axis travel	1300	mm
	Y axis travel	700	mm
	Z axis travel	650	mm
	Distance from spindle nose to table surface	150-800	mm
	Distance from spindle center to vertical column rail	785	mm
Table	Size	710*1400	mm
Table	Max. loading capacity	1000	kg
Spindle	Spindle taper	BT50
	Spindle speed	6000	rpm
	Spindle motor power	7.5-11	kw
Automatic tool changer	Tool capacity	24	pieces
Feed rate	Rapid traverse	≥10000	mm/min
Ball screw		HIWIN
Coupling		KTR
Accuracy	Repeatability	0.005	mm
Accuracy	Positioning accuracy	0.01	mm
Dimension	CNC system	GSK/FAGOR /SIEMENS/FANUC
Dimension	Machine weight(abt)	13T

MAIN PARTS

OTHER MILLING MACHINE OR VMC

OTHER MACHINES

PACKING

R&C

Dalian R&C Machinery Co., Ltd.: Contact nameAlice Liu; Phone86-411-87639858; AddressHuaguan Building, Dongbei Street, 120#, Development Zone, Dalian, Liaoning, China. Dalian,Liaoning
