MD200 Palletizer Robot Arm

Dalian R&C Machinery Co., Ltd.
MD200 Palletizer Robot Arm thumbnail-1
MD200 Palletizer Robot Arm photo-1
US$ 20,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
R&C
Model Number:
MD 200 industrial robot
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name R&C
Model Number MD 200 industrial robot
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1,MD200 palletizer robot;
2,Intelligent robot system;
3,High-torque motor;
4,Electrical cabinet and control



MD200  palletizer robot arm





IMAGE >> SPECIFICATION >> STALLATION>> OTHER ROBOTS >> OTHER MACHINES >>  PACKING >> R&C

MD200 palletizer robot armMD200 palletizer robot arm





IMAGE > SPECIFICATION>STALLATION > OTHER ROBOTS>PACKING>OTHER MACHINES> PACKING > R&C







Item

Type

MD120

MD200

Degree of Freedom

4

4

Drive System

AC servo motor

AC servo motor

Maximum Load Capacity

120kg

200kg

Position Repeatability

±0.1mm

±0.1mm

Motion Ability

1000return/hour(note)

1000return/hour(note)

Power Consumption

6KW

8KW

Movement Range

J1 Axis(Waist Basement)

±165°C

J2 Axis(Front-Rear)

1500mm

1500mm

J3 Axis(Up and Down)

2300mm

2300mm

J4 Axis (wrist)

±360°C



Environmental Condition

Temperature

0-45°C



Humidity

20-80%(No condensation)



Other

1.Keep away from flammable, explosive and corrosive gases and liquid

2.avoid water, oil and dust

3.Be away from electric appliance noise source(plasma)

Installation Posture

Installed on floor

Electric Cabinet Weight

125kg

Robot Body Weight

1300kg

1500kg











IMAGE >> SPECIFICATION >> STALLATION >> OTHER ROBOTS >> OTHER MACHINES >> PACKING >> R&C

MD200 palletizer robot armMD200 palletizer robot arm





IMAGE >> SPECIFICATION >> STALLATION >> OTHER ROBOTS>>  OTHER MACHINES >> PACKING >> R&C











MD200 palletizer robot arm





IMAGE >> SPECIFICATION >>  STALLATION >>  OTHER ROBOTS >>  OTHER MACHINES >> PACKING>> R&C

MD200 palletizer robot arm



MD200 palletizer robot arm



MD200 palletizer robot arm



MD200 palletizer robot arm



MD200 palletizer robot arm



IMAGE >> SPECIFICATION >> STALLATION >> OTHER ROBOTS >>  OTHER MACHINES >> PACKING >> R&C
MD200 palletizer robot arm



IMAGE >> SPECIFICATION >> STALLATION >>  OTHER ROBOTS >>  OTHER MACHINES>> PACKING >> R&C
MD200 palletizer robot arm



KINDLY CONTACT ME IF YOU NEED ANY INFORMATION.
MD200 palletizer robot arm
