25W Integrated All in One Solar Led Street Light

FOB Price

US$ 10 - 200 / Piece

10 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	LED	Input Voltage(V)	12V
Lamp Power(W)	25	Lamp Luminous Flux(lm)	2400-2600
Lamp Luminous Efficiency(lm/w)	120	Color Temperature(CCT)	Pure White
Working Temperature(℃)	-30, 70	Working Lifetime(Hour)	5000
Lamp Body Material	Aluminum Alloy	IP Rating	IP65
Certification	CE	Warranty(Year)	2
Place of Origin	Guangdong, China	Brand Name	southlight
Model Number	NFYG-L25

Product Description

integrated all in one solar led street light

Description:

1. All in one solar led street light , New invention with PRC & US patent.

2. From 8W to 40W.

3. Integration design, put solar panel, Led lamp, battery and cotroller all in a box, without any cable.

4. Installation easily, what you need to do when you receive them is to put them on the pole or wall, easy to ship, install and maintain.

5. CE, RoHS, IP65 in hand, ETL&UL certificate is coming

Parameters: (SSL-225)

Integrated Solar street light (25W)			Model: SSL-225
Solar panel	Max power	18V50W (monocrystalline silicon)
	Life time	25 years
Battery	Type	lithium battery
	Life time	5 years
LED Lamp (with sensor)	Max power	12V 25W
	led chip brand	Bridgelux from USA with high brightness
	lumen (LM)	2500-2750lm
	Life time	50000hours
	Viewing Angle	120°
Charge time	by sun	7 hours (with enough strong shine)
Discharge time	full power	more 10 hours
	saving mode	more 24 hours
working Temperature	range( °C )	-30°C~+60°C
colour temperature	range(k)	6000k
mounting height	range (m)	5-6m
space between light	range (m)	18-20m
Lamps material of main	aluminium alloy
Certificate	CE / ROHS / IP65
warranty period	2years
Packing & Weight	product size	108033050mm
	product weight	17kg
	packing size	1230400220 mm
	Corton size	1230400220 mm
	Q'ty/ctn	1sets/ctn
	GW.for corton	20kg
Packs Containers	20' GP	270sets
	40' GP	550sets

Features:

1. Integrated design without line, using wood,bamboo of lamstandard with low cost.

2. Using solar power, Led lamp for saving energy.

3. Using high power capacity and long life Lithium Iron Phosphate Battery.

4. Rain-proof structure

5. Main structure is made by alloy materialfor anti crossion

6. With different power control. Reducing luminance auotmatically.
