500W Pure Sine Wave Power Star Inverter

500W  pure sine wave  power star inverter

Technical parameters:

1.Input part

1)DC voltage: 12V/24V/36V/48V

2)Voltage range: 10-15VDC or 21-30VDC

3)No load current draw: <0.8

4)Efficiency: >92%

5)DC connection: Cables with clips

2.Output part

1)AC voltage: 100-120V or 220-240VAC

2)Continuous power: 500W

3)Surge power: 1000W

4)Waveform: Modified sine wave

5)Frequency: 50hz or 60hz

6)AC regulation: 5%

3.Protection part

1)Low voltage alarm: 10DC±0.5V or 20.5±1V

2)Low voltage shut down: 9.5DC±0.5V or 19.5±1V

3)Over load: shut off output

4)Over voltage shut down: 15.5V or 30.5V

5)Over thermal: shut off output automatically

4.Environment part

1)Working temperature: between -10°C and +50°C

2)Working humidity: 20% ~ 90% RH

3)Storage temperature: between -30°C and +70°C
