High Precison Spherical Roller Bearing 22312 KW33

High Precison Spherical Roller Bearing 22312 KW33 thumbnail-1
High Precison Spherical Roller Bearing 22312 KW33 photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Bore Size:
10, 2000
Outside Diameter:
20, 3000
Contact Supplier Request Quote Chat Now
Xian Pin-Guan Electro-Mechanic Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Bore Size 10, 2000
Outside Diameter 20, 3000

Specifications

Material: AISI52100 Chrome Steel, High precison Suffix:CA K W33 MB CC

High precison spherical roller bearing 22312 KW33



Suffix Numbering Systems:

Internal Structure and Retainer Types:

CC = Symmetrical Rollers, Stamped Steel Retainer

CA = Symmetrical Reinforced Roller,  one-piece  brass retainer

E = Reinforced structure; Extra Life Quality.

MB = Symmetrical reinforced Roller, Two piece Brass Retainers.

Outer Structures:

W20 = With Three Lubricating Holes on Outer Race

W33 = Lubricating Groove and Three Lubricating Holes on Outer Rac

K = Tapered in Bore, Inner Race is Tapered.

Internal Clearances:

C0 = Normal Internal Clearance (Standard will not indicate)

C2 = Less than Normal Clearance, Tight.

C3 = Larger Clearance than C0, Loose.

C4 = Larger Clearance then C3, Extra Loose.

Working Temperatures:

/S0 = Working Temp up to 150º C  (standard will not indicate)

/S1 = Working Temp up to 200° C

/S2 = Working Temp up to 250º C

/S3 = Working Temp up to 300° C

/S4 = Working Temp up to 350º C

Material: SAE-52100 Chrome Steel



21305 22205 22308 23022 23120 23218 23318 23926 24020 24122
21306 22206 22309 23024 23122 23220 23320 23928 24022 24124
21307 22207 22310 23026 23124 23222 23322 23932 24024 24126
21308 22208 22311 23028 23126 23224 23324 23934 24026 24128
21309 22209 22312 23030 23128 23226 23326 23936 24028 24130
21310 22210 22313 23032 23130 23228 23328 23938 24030 24132
21311 22211 22314 23034 23132 23230 23330 23940 24032 24134
21312 22212 22315 23036 23134 23232 23332 23944 24034 24136
21313 22213 22316 23038 23136 23234 23338 23948 24036 24138
21314 22214 22317 23040 23138 23236 23340 23952 24038 24140
21315 22215 22318 23044 23140 23238   23956 24040 24144
21316 22216 22319 23048 23144 23240   23960 24044 24148
21317 22217 22320 23052 23148 23244   23964 24048 24152
21318 22218 22322 23056 23152 23248   23968 24052 24156
  22219 22324 23060 23156 23252   23972 24056 24160
  22220 22326 23064 23160 23256   23976 24060 24164
  22222 22328 23068 23164 23260   23980 24064 24168
  22224 22330 23072 23168 23264   23984 24068 24172
  22226 22332 23076 23172 23268   23988 24072 24176
  22228 22334 23080 23176 23272   23992 24076 24180
  22230 22336 23084 23180 23276   23996 24080 24184
  22232 22338 23088 23184 23280   239/500 24084 24188
  22234 22340 23092 23188 23284   239/530 24088 24192
  22236 22344 23096 23192 23288   239/560 24092 24196
  22238 22348 230/500 23196 23292   239/600 24096 241/500
  22240   230/530 231/500 23296   239/630 240/500 241/530
  22244   230/560 231/530 232/500   239/670 240/530 241/560
  22248   230/600 231/560 232/530   239/710 240/560 241/600
  22252   230/630 231/600 232/560   239/750 240/600 241/670
  22256   230/670 231/630 232/600   239/800 240/630 241/710
      230/710 231/670 232/670   239/850 240/670 241/750
      230/750 231/800 232/710   239/900 240/710 241/900
      230/800   232/750   239/950 240/750 241/950
      230/850   232/800   239/1060 240/800
      230/900   232/900   239/1180 240/850
      230/950   232/1060     240/900
                240/950
                240/1000
                240/1060
                240/1120
