Boring milling machine DBM-110B Universal high quality CNC machine

FOB Price

USD $50,000 - $80,000 / Set

1 Set(Min.Order)

Supply Ability 40 Set / Sets per Month
Port Dalian
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Liaoning, China
Brand Name	R&C	Model Number	DBM110B
Type	Horizontal	CNC or Not	CNC
Voltage	380V/50Hz/3Ph	Power(W)	15/18.5
Dimension(LWH)	797060804990	Weight	34000KG
Certification	ISO9001 CE	Warranty	12 Months
After-sales Service Provided	Overseas service center available

Product Description

Boring milling machine DBM-110B Universal high quality CNC machine

Main Futures

With nice appearance overall,symmetry coordinate layout . Horizontal boring machine bed, column, down the seat rails are rectangular, and good stability. Guide the use of refrigeration hardened, high wear resistance. Synchronous digital display, intuitive and accurate, can improve efficiency and reduce costs.

Technical parameters

Model	Unit	DBM-110	DBM-110A	DMB-110B
X-axis travel (standard)	mm	2000	2000	2000
X-axis travel (optional)	mm	2500	2500	2500/3000/3500
Y-axis travel (standard)	mm	1800	1800	2200
Y-axis travel (optional)	mm
Z-axis travel (standard)	mm	1500	1500	1500
Z-axis travel (optional)	mm			2000
W-axis travel (standard)	mm	400	550	550
Spindle
Center of spindle worktable surface	mm	0~1800	0~1800	0~2200
Nose of spindle to work center	mm	100~2000	150~2200	150~2200
Spinde diameter	mm	110	110	110
Spindle taper		ISO 50	ISO 50	ISO 50
Rotating spindle speed (standard)	rpm/min	35~3500	35~3500	35~3500
Number of steps of rotating speed of spindle		2 Steps	2 Steps	2 Steps
Transmission mode		Gear box	Gear box	Gear box
Worktable
Table size (optional)	mm	1250×1500	1250×1500	1400×1600
Division angle	deg	0.001°	0.001°	0.001°
Reference aperture	mm	Φ60H7	Φ60H7	Φ140H7
Max. load on worktable	kg	5000	6000	8000
T-shot	mm	22H7×150×7	22H7×150×7	24H7×200×7
Division precision	sec	15	15	15 4
Transmission mode
X, Y, Z-axis		Direct-drive	Direct-drive	Direct-drive
W-axis		Belt-drive	Belt-drive	Belt-drive
Y-axis counterweight		Counter weight	Counter weight	Counter weight/ Hyd. Type
Cutting speed X/Y/Z/W	m/min	10/10/10/6	10/10/10/6	10/10/10/6
Rapid traverse speed X/Y/Z/W	m/min	10/10/10/8	10/10/10/8	10/10/10/8
Tool magazine and automatic toolchanger (optional)
Capacity of tool magazine		40	40	40
Tool selecting mode		Absolute	Absolute	Absolute
Tool changing type		Arm type	Arm type	Arm type
Tooling		BT/CAT/DIN #50	BT/CAT/DIN #50	BT/CAT/DIN #50
Max. tool weight	kg	25	25	25
Max. tool length	mm	500	500	500
Max. tool diameter (no adjacent tool)	mm	Φ125/250	Φ125/250	Φ125/250
Spindle and motor
Spindle motor	kw	FANUC 15/18.5	FANUC 15/18.5	FANUC 15/18.5
Max. torque of spindle	Nm	787/965	787/965	787/965
Precision
Locating precision of machine tool	mm	±0.010	±0.010	±0.010
Repetitive locating precision of machine tool	mm	±0.005	±0.005	±0.005

Main parts

Optional Attachment

Detailed Images

Packing & Delivery
