Home > Metallurgy, Mineral & Energy > Refractory Material > Special Refractory Material > Silicon Carbide Radiation Pipes
US$ 10.00 - 10.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Shape:
Pipe
Material:
Silicon Carbide (SiC)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Beijing Tianjing Lianyungang etc
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Silicon Carbide Cooling PipesUS$ 5 - 80MOQ: 5 Pieces -
1400 Degress Celsius SiSiC TubeUS$ 5 - 80MOQ: 1 Piece
-
Wear Resistance Mechanical Seal Rings Silicon Carbide Seal RingUS$ 0.1 - 50MOQ: 1 Piece
-
Sintered Silicon Carbide Ceramic Ring Precise Silicon Carbide RingUS$ 0.1 - 50MOQ: 1 Piece
-
High Quality Silicon Carbide Seal RingUS$ 0.1 - 50MOQ: 1 Piece
Place of Origin
China
Shape
Pipe
Material
Silicon Carbide (SiC)
SiO2 Content (%)
1.0%
Al2O3 Content (%)
38-42%
MgO Content (%)
0.8-1.2
CaO Content (%)
0.34%
CrO Content (%)
0.1~0.3%
SiC Content (%)
30-99
Model Number
SC-RT-01
Brand Name
JK
silicon carbide radiation
The silicon carbide radiation tube mainly be used in indirect furnace steel, metallurgical and other industries, their preheating furnace, Flame combustion furnace, tempering furnace, annealing furnace, quenching furnace, incinerator, etc. Pretreatment or heat exchange device of heat treatment equipment and radiator.
Item | Unit | Data | |||
RSiC | SiSiC | N-SiC | SSiC | ||
Bulk Density | (g/cm3) | 2.60-2.72 | ≥3.02 | ≥2.75 | 2.95 |
Porosity | % | ≤17 | ≤0.1 | 10 | 0.5 |
Bending Strength (4-point) | MPa(at20℃) | ≥ 90 | ≥250 | 150 | 350 |
MPa(1200℃) | ≥100 | ≥280 | 170 | 450 | |
Thermal Expanssion | 10-6 k-1 | 4.8 | 4.8 | 4.6 | 4.2 |
Thermal conductivity | W/m.k | 23 | 45 | 25 | 90 |
Youngs Modulus | GPa(20℃) | 240 | 320 | 280 | 420 |
Working Temp. | ℃ | 1650 | 1350 | 1450 | 1700 |
