PMAC735 Power Quality Analyzer

FOB Price

Negotiable / Unit

3 Units(Min. Order)

Port Zhuhai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	PILOT
Model Number	PMAC735	Measuring Current Range	1A or 5A (Via CT)
Measuring Voltage Range	120~277V, 57.7/100V(Via PT )	Accuracy Class	U, I:0.2% , kWh: 1
Operating Temperature	-20C~+60C	Dimensions	969618

Product Description

Specifications

1. Power Quality Analyzer, RS485 communication, accuracy up to 0.2%(U, I)
2. 31st harmonic analysis, SOE

Specifications

1. power meter measures voltage, current, power, power factor, kWh, kvarh
2. RS485/ Modbus
3. power quality analysis
4. DI/DO

PMAC735 Power Meter Features:

1. Suit for LV/ HV voltage system

2. Compact design with all real-time measurement

3. Consist of basic unit and optional modules

4. 10 years back-up of integrated energy data

5. Large LCD, high brightness, auto-scrolling

6. High accuracy, V or I is 0.2%, kWh is class 1

7. CT and PT programmable

8. Pluggable terminals, easy to install

9. Panel size: 96 x 96mm

10. Password protect

PMAC735 Power Meter Basic Function:

Provide one RS485 communication, measures and display real-time parameters:

1. Voltage—Ua, Ub, Uc, Uab, Ubc, Uca,

2. Current—Ia, Ib, Ic, In

3. Active power – Pa, Pb, Pc, ∑P

4. Reactive power –Qa, Qb, Qc, ∑Q

5. Apparent power—Sa, Sb,Sc, ∑S

6. Power factor—PFa, PFb, PFc, ∑PF

7. Frequency

8. Active energy—kWh (4 quadrant)

9. Reactive energy– kvarh (4 quadrant)

10. Demand and Max. record for I, P, Q, S

11. Unbalance rate for U, I

12. Max./ Min. value

PMAC735 Power Meter DI/ DO Modules:

1. 4 status input + 4 relay output

2. 8 status input + 2 relay output

3. 8 status input + 2 pulse output

4. Profibus communication module

PMAC735 Power Meter Optional Function:

1. Up to 31st harmonic analysis, K factor, THD

2. SOE (event log)

3. One 4~20mA analog output

Parameter	Accuracy
Voltage	0.2%
Current	0.2%
Power	0.5%
Power factor	0.5%
Frequency	0.01
Active power	1.0%
Reactive power	2.0%
THD	1.0%
Harmonic	1.0%
Unbalance rate	1.0%
