TWSL-500 battery production line battery production equipment 5 channel automatic 18650 sorter sorting machine

TWSL-500  battery production line battery production equipment 5 channel automatic 18650  sorter sorting machine

Payment & Shipping Terms:

Mode::twsl-500

Description

Product Details

product name: 18650 automatic sorting machine

Features:


TWSL-500 five-speed cylindrical cell sorter is a cylindrical batteries for internal resistance, voltage and other parameters of the test sorting equipment, comes with high-precision internal resistance, voltage automatic test system, the device can be set according to battery internal resistance, voltage fed to the specified precision gear, the system can achieve up to 5 sorting. This device can be tested per hour with a group of batteries around 4000, and the structure is simple and elegant design, stable performance, is by far the most cost-effective on the market of a sorting equipment.
model: TWSL-500



Operating Voltage: AC220V ± 10% 50HZ, power: ≤200 W
Working gas source : 0.5~0.6Mpa
Adaptation Battery Specifications: 18650
Separation efficiency: ≥65PPM
Weight: About 120 kg
Dimensions: 1200 (L) × 800 (width) × 1200 (H) mm
instrument : Precision voltage resistance tester HK3561
Sorting parameters: Open circuit voltage, AC resistance
Open circuit voltage: Accuracy +/- 0.1% rdg, display resolution 0.1 mV
AC resistance: Accuracy +/- 0.5% rdg, display resolution 0.01 mOhm
