PILOT PMAC201HW MODBUS Smart Energy Meter

PILOT PMAC201-HW MODBUS smart energy meter

PMAC201HW is a Din Rail Mounted intelligent multi-function power monitor. It is specifically designed to measure the power consumption of circuit within an electrical distribution board. It provides a cost effective solution to understanding energy consumption within your building. A quick and easy installtion, the PMAC201HW will mesure volts, amps, watts, active power, reactive power and frequency.

Features

1. Used for 4*3 phase or 12*1 phase circuit AC measuring

2. Rocord Power-on & Power off time and on/off period record

3. Record SOE (Event log) and modify setting event

4. Freeze data per 5 min. Total quantity is up to 20,000 (Max. one year data)

5. used18~72Vdc power supply

6. Support split core current transformer, primary side up to 100A, secondary side is 6.67mA

7. LED light for pulse output, Run and communication

8. Din Rail Mounted, Provide MODBUS communication protocol.

Technical specification

Dimension

Standard Current transformer

Typical application

1. In Telecommunication base

2. In Smart Building system

Products range:

Provide solution for:

Commercial Building

EMS

SCADA

DMS

Billing system

Telecommunication base

Data Center
