PILOT PBAT Sentinel Lead acid battery monitoring

PILOT PBAT Sentinel Lead acid battery monitoring

Battery Stethphone

• PBAT-802 : 2 volt Battery Cell Stethophone
• PBAT-812: 12 volt Battery Cell Stethophone
• PBAT-800: Battery string Stethophone

Monitoring and Records

• Voltage,interal resistance, negative temperature of per block
• Voltage, current of per string
• Alarm of Battery's state of charge and state of health
• Real time and History data records and curve analysis

 Easy installation -- You only need to plug-in

PILOT Gateway

• PBAT-GATE: Monitor Control gateway with Web view

PBAT GATE Function

•  Connect Max 250 unit PBAT cell stethophones
•  8GB TF card for 60 months monitor and data storage
•  Build in web server, display data by web view pages
•  Anaysis monitor curve and judge battery SOC & SOH
•  Battery switch status, humidity & temperature monitor
•  Transmit data & alarm to cloud server by TCP/IP
•  Email and GSM message as optional function

System Structure

Application

PBAT-802

Mornitoring Room

 Monitoring Room

String Monitor PBAT-800

& PBAT GATE Monitoring Web Server
