TM280 Ultrasonic Thickness Gauge

Name: TM280 Ultrasonic Thickness Gauge
Brand: TMTECK
SKU: 103619335

US$ 100 - 1,200 MOQ: 1 Piece

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

TMTECK

Model Number:

TM280

TMTeck Instrument Co., Ltd. (Beijing)

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name TMTECK

Model Number TM280

TM280 Series Technical Specifications

Feature	TM280	TM280D	TM280DL	Data Logger Option
Color Display	√	√	√
LiveA-Scan	√	√	√
Time-based B-Scan	√	√	√
Control of Gain, Blanking,Gate, Range, Delay, RFand Rectify Modes	√	√	√
Echo-Echo Mode (Thru-paint &Coatings)	×	√	√
Data Logger	×	×	√	√
DataView Software	×	×	√	√

Instrument Specifications
Display Type	2.4” color OLED, 320 X 240 pixels, contrast 10,000:1
Operating Principle	Pulse echo with dual element transducers
Measuring Range	0.50mm to 508mm(0.02” to 20.00"), depending on material, probe and surface condition
Measuring Resolution	Selectable 0.01mm, 0.1mm(selectable 0.001", 0.01")
Units	Inch or Millimeter
Rectify Modes	RF+, RF-, HALF+, HALF-, FULL
Display Mode	Normal, Minimum / Maximum capture, DIFF/RR%, A-Scan, B-Scan
V-Path Correction	Automatic
Update Rate	Selectable 4Hz, 8Hz, 16Hz
Material Velocity Range	500 to 9999m/s (0.0197 to 0.3937in/us)
Languages	English
Alarm Settings	Minimum and Maximum alarms. Range of 0.25 mm to 508 mm (0.010" to 20.00"). Dynamic waveform color change on alarm
Power Requirements	2 AA size batteries
Operating Time	Approximately 40 hours
Instrument Shut-off	Selectable ALWAYS ON or AUTO OFF after 5, 10, 20 minutes of inactivity
Operating Temperature	-10°C to +50°C (+10°F to +120°F)
Size	153mm X 76mm X 37mm(H X W X D)
Weight	280g including batteries

TM280 Probe/Transducer Specifications
Model	PT08	TC510	PT12	ZT12	PT06	PT04	GT12
Type	TM280 Standard	TM280D/DL Standard	Standard	Cast iron	Small tube	Fingertip	High- Temperature
Frequency	5MHz	5MHz	5MHz	2MHz	7.5MHz	10MHz	5MHz
Contact Diameter	11mm	13.5mm	13.5mm	17mm	8mm	6mm	15mm
Measurement Range	0.8 to 100.0mm	1.2 to 200.0mm	1.0 to 200.0mm	4.0 to 508mm	0.8 to 30mm	0.7 to 12mm	4 to 80mm
Temperature Range	-10 to 70℃	-10 to 70℃	-10 to 70℃	-10 to 70℃	-10 to 70℃	-10 to 70℃	-20 to 300℃
