Specifications
1.CCC,CE,ISO9000 Certificate.2.Frame Size:71-160
3.Capacitor start.
4.Suit for small size machine tools and water pumps.
♦INTRODUCE
♣The YC series heavy-duty single-phase motors are suitable for powering small type machine tools and water pumps,especially for family workshops where only single-phase current is available.Motors of this series are integrated with up-to-date design,built with the best quality materials and attractive appearance.They have outstanding performance,easy maintenance and are reliable.They completely conform to international I.E.C. standards.
♣YC series protected motors are of IP44 totally enclosed fan-cooling type.Under reted voltage and 50Hz,the starting torque is three times more than the rated torque and 60Hz is more than 2.75 times.Motors for 4 HP and over are of capacitor start and run type.They all have the advantage of high starting torque,smooth running,low temperature rise,low noise and greater overload performance.
♦OPERATING CONDITIONS
♣Ambient temperature:-15°c<Θ<40°c
♣Altitude:not exceed 1000m
♣Rated voltage:220v
♣Rated frequency:50Hz/60Hz
♣Dyty:S1(continuous)
♣Insulation class:B/F
♣Protection class:IP44/IP54
♣Cooling method:IC0141
| Types | YC,Y2,YE2,YC,YD YS,IE,YL,YY |
| Standard | IE1,IE2 |
| Phase | single phase/three phase |
| Housing | Aluminum/Cast Iron |
| Certificate | CE,ISO9001,CCC |
| Rated voltage | 220v/380v/440v |
| Bearing | NSK/SKF |
| Lamination | Cold Rolled steel 1800/DR510 |
| Wire | 100% copper |
| Power | 0.18kw-315kw |
| Frame size | 50-200mm |
| Poles | 2,4,6 |
| Duty | S1,S2,S3 |
| Insulation class | B,F,H |
| Protection class | IP44,IP54,IP55 |
| IM | Horizontal/vertica |
| Delivery time | 30% deposit after 30 days |
| Package | Ply-wooded box/pallets |
Our serves
Inquiry response:Your inquiry will be replied in 24 hours.
Delivery time:Your shipment will be loaded in 25-30days,depend on quantity
Payment term:T/T, L/C, D/P .
