AT-289 Walkie Talkie With FCC,RoHS&CE Approval

Qixiang Electron Science&Technology Co., Ltd. Quanzhou
AT-289 Walkie Talkie With FCC,RoHS&CE Approval thumbnail-1
AT-289 Walkie Talkie With FCC,RoHS&CE Approval photo-1
US$ 30 - 65 MOQ: 100 Sets
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Anytone
Model Number:
AT-289
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Anytone
Model Number AT-289
Type Handheld
Dimensions 260*60*35mm
Frequency Range 136-174MHz/400-480MHz
Storage Channel 128Channel
Talk Range 5-10Km

AT-289 walkie talkie with FCC,RoHS&CE approval

Frequency: 136~174MHz, 350~390MHz,
                    400~470MHz, 470~512MHz
Function:
  Output power 4/5W,  16X16=256 channels.
  Water protection class IP55, Voice ann-
  unciation (Chinese or English or Russian).
  CTCSS+DCS encode and decode.
  Multi-Scan mode: VFO scan+channel
  scan+priority scan+CTCSS scan+DCS
  scan.
  VOX function (6 levels), voice scramble &
  compander, wide/narrow band.
  Squelch Tail Elimination function.

Battery power check up.

Accessories:
  One charger
  One Li-ion battery(1300mAh)
  One rubber antenna
  One user's manual

General

Frequency Range

VHF: 136-174MHz    UHF:350-390MHz

UHF: 400-470MHz    UHF:450-520MHz

Channel Capacity

128 channels

Channel Spacing

25KHz(Wide Band) 20KHz(Middle Band) 12.5KHz(Narrow band)

Phase-locked Step

5KHz,6.25KHz

Operating Voltage

7.4V  DC ±15%

Battery Life

More than 14 Hours (1350mAh), by 5-5-90 working cycle

Frequency Stability

±2.5ppm

Operating Temperature

-20°C +55°C

Size

260×57×37mm (with battery, antenna)

Weight

210 g (with battery, antenna)

Receiver (ETSI EN 300 086 standard testing )



Wide band

Narrow band

Sensitivity (12dB Sinad)

≤0.25μV

≤0.35μV

Adjacent Channel

Selectivity

≥70dB

≥60dB

Intermodulation

≥65dB

≥60dB

Spurious Rejection

≥70dB

≥70dB

Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~2.55KHz)

Hum & Noise

≥45dB

≥40dB

Audio distortion

≤5%

Audio power output

500mW / 10%

Transmitter (ETSI EN 300 086 standard testing )



Wide band

Narrow band

Power Output

4W/2W/0.5W

Modulation

16KΦF3E

11KΦF3E

Adjacent Channel

Power

≥70dB

≥60dB

Hum & Noise

≥40dB

≥36dB

Spurious Emission

≥-36dB

≥-36dB

Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~2.25KHz)

Audio Distortion

≤5%



AT-289 walkie talkie with FCC,RoHS&CE approval





AT-289 walkie talkie with FCC,RoHS&CE approval
