2.4GHz Wireless Camera Pen With DVR,Small Pen Camera Recorder With DVR

Shenzhen Global Technology Co., Ltd.
2.4GHz Wireless Camera Pen With DVR,Small Pen Camera Recorder With DVR thumbnail-1
2.4GHz Wireless Camera Pen With DVR,Small Pen Camera Recorder With DVR photo-1
US$ 165 - 170 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SOMAX
Model Number:
SM-WIR0027
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SOMAX
Model Number SM-WIR0027
Type Other, Digital Camera, Video Camera
Style Mini Camera
Sensor CMOS
Technology Pinhole
Special Features Other, 800X600 Resolution

Specifications

1.2.4GHz Wireless Camera Pen with DVR
2.3.5"TFT LCD screen with up to 800X600 resolution
3.Small Pen,30fps

2.4GHz Wireless Camera Pen with DVR,Small Pen Camera Recorder with DVR



Feature:

*Wireless transmission provides real time video on DVR to view effect as you record;
*Mini camera hides into a super thin working pen ;
*Near and far focus available for choice (near focus for small text record);
*3.5"TFT LCD screen with up to 800X600 resolution
*Video Format: Mpeg-4,AVI (800 or 320 @ 30fps) MP4,3GP
*Memory: built-in flash :2GB~8GB; support SD card 1GB to 16GB
*380TV line for clear image;
*4 channels available to avoid possible interference;
*Built-in antenna and rechargeable Li-battery;
*Min. 100m transmission distance without blocks

Specification:



 Transmission Frequency
 ISM 2,400MHz~ 2,483MHz    4CH*
 Modulation Mode
 FM
 Antenna Type
 Hidden
 Unobstructed Effective Range
 100m(Without Block)
 Operating Temperature
 0~ +50 / +14~ +122
 Storage Temperature
 -20 ~ +60 / -4 ~ +140
 Operating Humidity
 85%RH
 CAMERA
Transmission Frequency
ISM 2,400MHz~ 2,483MHz  CH1 CH3
Audio subcarrier frequency
6.0Mhz
Antenna
Built-in 2.4G antenna
Transmitting Range
300 feet in line of sight
CMOS Total Pixels
510×492(NTSC)
Horizontal resolution
380TV line
Frame rate
30FPS
Built-in mic.
55dB high sensitivity
View Angle
62°
Camera lens focus
Beyond3m vicinity:10cm
Minimum Illumination
3.0 Lux / F1.5
Transmission Power
 10mW
Battery Performance
 Li-ion Battery 160mAH
Working Time
 1.5 hours
Charge time
1 hour
Operating voltage
DC 5V
Operating current
95MA
Color
 Golden/Silver
Dimensions( LX D)
144X12 mm
Weight
 30g
 RECEIVER
Receiving CH
 CH1~CH4
Sensitivity
 -92dB
LCD
 3.5 inches TFT
AV out
 NTSC / PAL
Resolution
 640*480 / 320*240
Video compress
 MPEG-AVI    30fps
Play format
 RM / RMVB / 3GP / MP4 / FLV / AVI / ASF / WMV /  DAT / VOB / MPG
Frequency
 20HZ-20KHz  stereo
Earphone Output
 Left: 20MW+ right 20mW [16O](suit to largest volume)
Play format
 MP3 / WMA / AMR / AAC / FLAC / APE
Speaker
 0.6W
File format
 JPG/JPEG
FLASH
 2GB-8GB default 2GB
Outer SD card
 TF card 1GB-16GB( optional purchase)
IBM-PC
 Windows 2000XP & VISTA
Port
 HI-USB 2.0
Language
 Multiple languages
AC adapter
 DC 5V 2A
Built-in battery
 Li-battery 1200Mah
Wireless record
 ≥2.5 hours
Video record
 ≥5 hours
