Gabion factry of cage de gabion(Low price for sale) China Manufacture
Brief Description of Gabion Basket of Double twisted hexagonal mesh
Galvanized Gabion Basket /PVC Coated Gabion Basket
Surrface treatment :
hot-dipped galvanized (Zinc coating: 240-290g/m2)
PVC coated
galfan (5% Zn-Al alloy gabion or 10% Zn-Al alloy gabion)
Mesh size :6X8,8 X 10, 10 X 12
Meet ASTM and BS Standard
Our company is Golden supplier Assessed by third party
Wire diameters, relevant tolerances and zinc coating shall be in accordance with the following table:
Use |
Units |
Lacing |
Mesh |
Selvedge |
Galvanized + PVC |
Ø mm |
2,2 2,2/3,2 |
2,7 2,7/3,7 |
3,4 3,4/4,4 |
Wire Tolerance |
Ø mm |
±0,08 |
±0,08 |
±0,1 |
Quantity of zinc |
g/m2 |
245 |
275 |
275 |
Tensile strength |
N/mm2 |
350-575 |
||
|
According to SANS 675:1997 According to SANS 1580:2005 and SANS 675:1997 | ||||
Specification of Gabion Basket:
Specification of Double twisted hexagonal mesh | |||
|
Opening (mm) |
Wire Diameter (mm) |
PVC Wire Diameter Inside/outside (mm) |
Max Breadth (m) |
60X80 |
2.0-2.8 |
2.0/3.0-2.5/3.5 |
4.3 |
80X100 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
4.3 |
80X120 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
4.3 |
100X120 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
4.3 |
100X150 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
4.3 |
120X150 |
2.0-4.0 |
2.0/3.0-3.0/4.0 |
4.3 |
Others we can do as your requirement | |||
Size |
Note |
Tolerance |
|||
Length(m) |
Width(m) |
High(m) |
Diaphragm |
Volume(m3) |
L +/-3% W+/-5% H+/-5% |
2.0 |
1.0 |
0.3 |
1 |
0.6 |
|
3.0 |
1.0 |
0.3 |
2 |
0.9 |
|
4.0 |
1.0 |
0.3 |
3 |
1.2 |
|
2.0 |
1.0 |
0.5 |
1 |
1.0 |
|
3.0 |
1.0 |
0.5 |
2 |
1.5 |
|
4.0 |
1.0 |
0.5 |
3 |
2.0 |
|
1.0 |
1.0 |
1.0 |
0 |
1.0 |
|
1.5 |
1.0 |
1.0 |
0 |
1.5 |
|
2.0 |
1.0 |
1.0 |
1 |
2.0 |
|
3.0 |
1.0 |
1.0 |
2 |
3.0 |
|
4.0 |
1.0 |
1.0 |
3 |
4.0 |
|
Application
1.Control and guide of water or flood
2.Flood bank or guiding bank
3.Preventing of rock breaking
4.Water and soil protection
5.Bridge protection
6.Strengthening structure of soil
7.Protection engineering of seaside area.
Galvanized/Galfan finishing gabion retaining wall price, gabion baskets for sale
PVC Coated gabion retaining wall price, gabion baskets for sale
Detailed information:
1. Materials: Low carbon steel wire, stainless steel wire, electro galvanized wire, hot-galvanized wire, heavily galvanized wire, pvc-coated wire.
2. Weaving processing: twisted before galvanized, weaving after galvanized.
3. Available:
· Electro Galvanized before Weaving
· Electro Galvanized After Weaving
· Hot Dipped Galvanized before Weaving
· Hot Dipped Galvanized after Weaving
· PVC Coated Before or After Weaving
|
4.Uses: (1).Strengthen the slopes (4).The work of Gabion are considered to be a perfect solution in demanding geotechnical conditions, because you can easily assemble. |
|
|
5. Roads and railways: Gabion is used where it is necessary to stabilize the road or rail. It is used primarily for the expansion or construction of roads on the slopes. Furthermore, in the construction of railway embankments, and so on. Another option is the use of Gabion noise barriers, where the effect is compared with soundproof concrete improved by selecting suitable plants. |
6.Rivers:
|
Gabion provides clear advantages in the management of watercourses. Gabion works better than the concrete lining, which destroys any connection between water flow and its surrounding areas and prevents the growth of plants. |
7. Gabion Basket applications:
1)Control and guide of water or flood
2)Flood bank or guiding bank
3)Preventing of rock breaking
4)Water and soil protection
5)Bridge protection
6)Strengthening structure of soil
7)Protection engineering of seaside area.
8. Gabion cage features:
1)An economy. Just a stone into a cage sealing
2) construction is simple, no special skills.
3)strong to withstand natural damage and corrosion resistance and resistance to adverse climate impacts.
4)Can withstand a wide range of deformation, but not collapse.
5) silt stones is conducive to plant production, and the natural environment as a whole.
6 )has a good permeability to prevent the damage caused by the hydrostatic
7)Save on shipping costs. Can be folded up and transport, assembly on site.
9.Usage:
10.Working:
Workers checking the depth of subgrade reinforcement gravel on a pavement patch. |
Workers installing gabion baskets on the South Fork Salmon River Road. |
11.Workshop:
12.Warehouse:
13.Loading:
