Hot Sale Gatherings Control Barrier for Control Large Gatherings
Specifications
Gatherings Control BarrierGatherings Control Barrier 2.3m
mobile Gathering Control Barrier
portable Control Barrier
ISO9001
hot sale Gatherings Control Barrier for Control Large Gatherings
1. APPLICATION OF Gatherings Control Barrier
LIGHTWEIGHT ECONOMY INTERLOCKING RAILING, also known as pedestrian barrier, is an effective crowd control
and site demarcation product extensively used in public areas, such as event, sport venue, public rallies, demonstration,
outdoor festival, concerts. They are considered versatile with the following functions:
- Direct pedestrian traffic.
- Keep the crowd in a designated area.
- Protect cordoning off restricted areas.
- Designate space for lines.
- Control large gatherings.
- Deter motorists and pedestrian entering.
- Create allocated walkways.
- Also can be used at construction sites and road works
2. THE FEATURE OF Gatherings Control Barrier
OVERALL WIDTH IS: 20 1/8" OVERALL LENGTH IS: 98 11/16"
OVERALL HEIGHT IS: 39 5/16"
DISTANCE BETWEEN VERTICAL BARS IS: 5 7/8"
INCLUDES CONNECTORS TO ATTACH MULTIPLE UNITS TOGETHER
INCLUDES TWO CURVED FEET FEET
ARE REMOVABLE FOR STORAGE AND SHIPPING
GALVANIZED FINISH
3. WHY CHOOSE OUR Gatherings Control Barrier ?
Three types of bases:
The CLASSIC INTER LOCKING RAILING are composed of crowd control panels and barrier bases which are welded or bolted
to the barrier. Our CASSIC INTER LOCKING RAILING are manufactured with fix base, flat base or bridge base as shown in the
picture of lightweight economy interlocking CASSIC INTER LOCKING RAILING:
Gatherings Control Barrier CCB-001
Gatherings Control Barrier CCB-002
Gatherings Control Barrier 2.3m CCB-003
4. THE FURTHER DETAIL OF Gatherings Control Barrier
Gatherings Control Barrier CCB-1:
- With fixed leg welded to the frame permanently.
- Ideal for public event areas where the speed of installation, dismantling and high security are the main concerns.
- Perfect for directing foot traffic.
Gatherings Control Barrier CCB-2:
- With removal and replaceable flat legs bolted on the panels
- Easy storage, transportation and stacking together.
- Much more stable and safer.
- Flat leg design minimizes the trip hazard.
Gatherings Control Barrier 2.3m CCB-3:
- Bridge shaped legs
- Removal and replaceable bases
- The most stable type
5. THE FRIEF INFORMATION OF THESE THREE STYLES Gatherings Control Barrier
Interlocking design the Gatherings Control Barrier can be attached to each other in a line or take corners of up to 90 degrees.
Once the barriers interlocked,it is not easy to topple them over.anels with single or double hooks are available as your request.
Normally, the two hooks can be manufactured 15 or 25 inches apart Crowd Control Barrier 2.3m take Hand welded with high
strength. crossover points of portable barricades are 360 degrees welded complying with advanced welding technology.
Gatherings Control Barrier take Portable frame for handling. Before being interlocked,the crowd control barriers can be lifted
just by individuals. Its portable character makes the panels easier to handle, install and transport.
Gatherings Control Barrier take hot dipped galvanized for rust resistance. We select the best galvanization way for the super
rust and corrosion resistance-that is hot dipped galvanized after welding.The thickness of the zinc layer is no less than 42 After
galvanization, they are more anti-weather and durable with a longer service time. If you are in a tight budget,other galvanization
ways are also available.
Gatherings Control Barrier 2.3m take PVC coating with various colors.The Gatherings Control Barrier can be PVC coated in
any color to fit your scheme and provide aesthetic effects.Details of portable barricades Material:gauge16 tubular steel Welded
way: 360 degrees hand welded.Technology standard:hot dipped galvanized after weldingZinc standard: 42 microns,300g/m2 Spe
cification of Gatherings Control Barrier :
Panel size |
Outer frame |
Upright tube |
Spacing |
|||
|
Length (mm) |
Height (mm) |
Outer diameter (mm) |
Thickness (mm) |
Outer diameter (mm) |
Thickness (mm) |
From 100mm to 200mm as your request |
2000 |
1500 |
38 |
2 |
16 |
1.5 |
|
2015 |
1100 |
38 |
1.2 |
12 |
0.7 |
|
2200 |
1100 |
25 |
2 |
20 |
1 |
|
2400 |
1100 |
25 |
2 |
20 |
1 |
|
2400 |
1100 |
38 |
1.2 |
16 |
0.7 |
|
2400 |
1200 |
40 |
2 |
20 |
1 |
|
2500 |
1100 |
25 |
2 |
20 |
1 |
|
2500 |
1100 |
26 |
2.5 |
15 |
1.5 |
|
2500 |
1100 |
38 |
2 |
16 |
1 |
|
2500 |
1150 |
35 |
1 |
16 |
1 |
|
2500 |
1100 |
38 |
2 |
16 |
1 |
|
6. PACKAGING & SHIPPING OF Gatherings Control Barrier
Gatherings Control Barrier FOR TOGETHER AND WAITING FOR DELIVERY
PVC COATED, SPECIAL DESIGNED Gatherings Control Barrier ARE ALSO AVAILABLE
