Specifications
Cattle panel(ISO9001)Hot-dipped galvanized finish
Height :1.8m
Length:2.1m
6x40x40 Bull rail
galvanised 40x40 SHS RAIL cattle panel
Materials: Carbon steel
Corrosion Form: hot-dipped galvanized or paint
Features: It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.
Main markets: Australia, European countries, Canada, America and Asia countries.
Description:
-1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails.
-Complete with Caps & Foot plates.
-Holes for ground pin on one leg of each panel.
-Elongated lug holes in brackets, for ease when connecting.
Specification
Specification |
Normal size |
Height x Length |
1.8m x 2.1m, 1.6 x 2.1m, 1.8m x 2.4m and so on |
pole style |
Round pipe or square tube or oval tube |
Pole specification |
32mmO. D, 42mmO. D, RHS40mm, RHS50mm and so on |
Package details |
In steel pallet or in bulk |
Different specifications are available according to customers' special inquiry or detailed drawings.
1)Round style livestock panels(Style 1)
Hot-dipped galvanized cattle panels
Height x Length :1.8x2.1m
Round pipe:40mm OD x 1.6mm thickness
2 joining pins supplied
Package: in high quality pallet
Round style livestock panels(Style 2)
Hot-dipped galvanized cattle panels
Height x Length :1.8x2.1m
Round pipe:32mm OD x 1.6mm thickness
2 joining pins supplied
Package: in high quality pallet
2) Oval tube style cattle panel
Hot-dipped galvanized cattle panels
Height x Length :1.8x2.1m
Vertical pipe:40x40mm RHS x 1.6mm thickness
Horizontal pipe:30x60mm oval rail x 1.6mm thickness
2 joining pins supplied
Package: in high quality pallet
3)Square tube style livestock
Hot-dipped galvanized cattle panels
Height x Length :1.8x2.1m
Square pipe:40x40mm RHS x 1.6mm thickness
2 joining pins supplied
Package: in high quality pallet
4) panel gates
Outside frame 2250mm (high) x 2100mm (long) x 40x40mm x 1.6mm square tube
Gate 1800mm (high) x 2030mm (long) x 30X60mm x 1.6mm oval tube - 6 bar
Hinges 2 Hinges to support gate
Catch Slam catch
Details showroom
Loading containers
