pure sine wave home ups inverter with charger
Negotiable
/ Piece
100 Pieces(Min.Order)
- 1000 Piece / Pieces per Month
- shenzhen
- T/T
You May Like
- electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
- 45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
- EM15-G3 General used Vector control Frequency inverter(3 phase )
- EMHEATER soft starter
- EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
- Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
Place of Origin: | Guangdong, China | Brand Name: | hksantek | Model Number: | T series |
Output Power: | Other, 300W~1200W | Output Type: | Single | Size: | 123*356*189 |
Weight: | 12KG | Input Voltage: | 220vac | Output Voltage: | 220vac |
Type: | DC/AC Inverters | Output Frequency: | 50/60hz | Output Current: | 15~30A |
Product Description
Specifications
pure sine wave home ups inverter with charger1, big charge current
2,with AVR
3,optional RS232 and USD
pure sine wave home ups inverter with charger
Application:
PC, workstation, printer
Features:
1. Wide input voltage window
2. Boost and buck AVR
3. Cold start function
4. Protection for overcharge, deep discharge and automated charge current regulation
5. Wide input frequency range and compatible with small generators
6.Intelligent battery management
7.Dry contact communication with monitoring software
8.Optional RS232 and USB
Model | 500VA | 1000VA | 1500VA | 2000VA |
Power Capacity (VA/W) | 500VA/300W | 1000VA/600W | 1500VA/900W | 2000VA/1200W |
Voltage(Battery Mode) | 220V±15%, or 110V±5% | |||
Voltage Range | 165~275Vac±4% or 80~135Vac±4% | |||
Frequency | Follow utility(Line mode),50Hz/60Hz±0.5Hz(Battery mode) | |||
Frequency Range | 40~70Hz ± 1Hz, or 55~65Hz ± 1Hz | |||
Power Factor | 0.6 | |||
Waveform | Modified sine wave | |||
Transfer time | Less than 4ms from battery to line,less than 8ms from line to battery. | |||
Backup time | >3ms | |||
Battery | ||||
Type | 12V Sealed Lead-Acid Maintenance free battery | |||
Charge current | 1.2A Max | 1.5A Max | ||
Recharge | After fully discharged,charge 8 hours to 90% capacity | |||
LED/LCD Indicators | Load Lever/Battery lever,battery,Utility Power,Inverter,Bypass,overload,default. | |||
Protection | Fuse | |||
Audible Alarm | Bypass,on battery mode,battery low,overload, fault | |||
Acoustic Noise | At 1 meter distance,<45dBA | |||
Communications | RS232 ,USB(Optional) | |||
Environmental | ||||
Operating Temperature | 0~40°C non-condensing | |||
Operating Humidity | 5~95% non-condensing | |||
Net Weight(kg) | 9.3/7 | 10 | 12 | 13 |
Dimensions W*D*H(mm) | 123*356*189 |
