Solid Ditital Blue Ultraschall-stift

Name: Solid Ditital Blue Ultraschall-stift
Brand: Solid
SKU: 103564981

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

Solid

Model Number:

Lpad H200

Solid (Beijing) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name Solid

Model Number Lpad H200

Specifications

1.Different Hardness Scales Display
2.Threshold Alarm
3.Massive Data Memory
4.USB Memory
5:Easy Operation

Solid ditital blue ultraschall-stift

1.Different Hardness Scales Display
2.Threshold Alarm
3.Massive Data Memory
4.USB Memory
5:Easy Operation

Product Description

Advantages

Spercifications

Measuring Direction	Universal (Up,Inclined Up, Down, Inclined Down ,Level)
Measuring Range	(170-960)HLD,(17.9-69.5)HRC,(19-683)HB,(80-1042)HV,(30.6-102.6)HS, (59.1-88)HRA, 13.5-101.7)HRB
Hardness Scale	H ,HB , B(HRB), C(HRC) , A(HRA) , HV , HS
Accuracy	±0.5%(HLD=800)			Indication Repeatability 0.8%
Display	High contrast 128x64 LED Beautiful printed characters ,Number , Symbol, High Brightness EL Backlight
Memory	Data Sets: 600 files	Data Scan Yes			Language: Chinese /English
	USB for Storage : connection USB is allowed ,there is no need other software for reading results
Power	Battery: 1.5V AA Battery*2			Low Battery Indicator: Yes
	Power Off : Auto			Working Time: Over 200 hours
Environment	Operation Temperature-10-50°C		Storage Temperature:-30°C-60°C			Relative humidity≤90%
Standard Package	Main Body 1			Carrying Case 1
	D Impact Device 1			Standard Block 1
Materials	Steel and Cast Steel ,Alloy Working Steel ,Stainless Steel, Gray Cast Steel, Ductile Iron, Casting Aluminum Alloy, Brass, Bronze, Cooper, forged steel
Applying Area	Axe or other parts Analysis of pressure vessel,turbine and other devices invalid; heavy working pieces; Installed machines or permanent assembly; Working pieces with a narrow testing space; Regular and original report are required; Metal material warehouse material distinction ; Large scale work pieces in several big range measuring parts of the rapid inspection
