1*32 Optical PLC Splitter With FC/PC

Name: 1*32 Optical PLC Splitter With FC/PC
Brand: LINKET
SKU: 103557041
Availability: InStock

US$ 7 - 86 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

LINKET

Model Number:

1*32 Cassette PLC Splitter with FC/PC Connector

Changzhou LINKET Electronics Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Shenzheng

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name LINKET

Model Number 1*32 Cassette PLC Splitter with FC/PC Connector

Our Advantage-Integrated Total Chain, Direct Factory Price

Production/Manufatcurer Level	Cut Wafer and Produce Chips	Make V-Groove	Make Fiber Array	Coupling	Produce Patch Cords and Install Connector
1st Level (LINKET)	√	√	√	√	√
2nd Level		√	√	√	√
3rd Level			√	√	√
4th Level				√	√
5th Level					√
LINKET intergrates the total chain, is the top-level PLC Splitter manufacturer in China. With over 10K/day production capacity, our PLC Splitters occupy over 40% market share in China.

Technical Specs for PLC Splitter with Connector

Item	1x2	1x4	1x8	1x16	1x32	1x64	1x128
Fiber Type	G.657.A
Working Wavelength	1260nm~1650nm
Standard Insertion Loss (dB)	≤4.2	≤7.4	≤10.6	≤13.9	≤17.2	≤20.8	≤24.0
P- Grade Insertion Loss (dB)	≤4.0	≤7.1	≤10.4	≤13.7	≤16.9	≤20.4	≤23.7
Uniformity (dB)	≤0.6	≤0.8	≤0.8	≤1.0	≤1.5	≤2.0	≤2.0
PDL (dB)	≤0.2	≤0.2	≤0.3	≤0.3	≤0.3	≤0.4	≤0.5
Wavelength Dependent Loss (dB)	≤0.6	≤0.8	≤0.8	≤1.0	≤1.5	≤2.0	≤2.0
Return Loss (dB)	≥50
Directivity (dB)	≥55
Operating Temp. Gange	-40℃~ +85℃
Note: The above parameter is for Splitter with connector. If w/o connector, insertion loss will reduce by 0.2dB.

Item	2x2	2x4	2x8	2x16	2x32	2x64	2x128
Fiber Type	G.657.A
Working Wavelength	1260nm~1650nm
Standard Insertion Loss (dB)	≤4.4	≤8.0	≤11.0	≤14.6	≤17.8	≤21.0	≤24.4
P- Grade Insertion Loss (dB)	≤4.2	≤7.7	≤10.8	≤14.1	≤17.4	≤20.7	≤24.0
Uniformity (dB)	≤0.8	≤1.0	≤1.2	≤1.5	≤1.8	≤2.0	≤3.0
PDL (dB)	≤0.2	≤0.2	≤0.3	≤0.3	≤0.3	≤0.4	≤0.5
Wavelength Dependent Loss (dB)	≤0.8	≤1.0	≤1.2	≤1.5	≤1.8	≤2.0	≤3.0
Return Loss (dB)	≥50
Directivity (dB)	≥55
Operating Temp. Gange	-40℃~ +85℃
Note: The above parameter is for Splitter with connector. If w/o connector, insertion loss will reduce by 0.2dB.

Encapsulation Size for PLC Splitter Module
