Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > High Shear Vacuum Emulsifier or Emulsifying Pump

High Shear Vacuum Emulsifier or Emulsifying Pump

Name: High Shear Vacuum Emulsifier or Emulsifying Pump
Brand: CHILE
SKU: 103503665
Availability: InStock

High Shear Vacuum Emulsifier or Emulsifying Pump thumbnail-1

High Shear Vacuum Emulsifier or Emulsifying Pump thumbnail-2

High Shear Vacuum Emulsifier or Emulsifying Pump thumbnail-3

High Shear Vacuum Emulsifier or Emulsifying Pump photo-1

High Shear Vacuum Emulsifier or Emulsifying Pump photo-2

High Shear Vacuum Emulsifier or Emulsifying Pump photo-3

US$ 100 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Homogenizer

Product Type:

Cosmetic

Contact Supplier Request Quote Chat Now

Chile (Shanghai) Machinery Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Homogenizer

Product Type Cosmetic

Application Liquid with Suspended Solids

Additional Capabilities Milling

Place of Origin Shanghai, China

Brand Name CHILE

Model Number CLRB

Max. Loading Capacity 50m³/h

Voltage 380V, 50/60Hz, can be customized

Power(W) 1.1~55kw

Dimension(L*W*H) depend on model

Certification CE, ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

High shear vacuum emulsifier or emulsifying pump

Product Description

One-stage Inline High Shear Emulsifier

1.precision stator and rotor inside;
2.flow 0.5-50m3/h
3.inline mixer

1. Main Features

a. Inline High Shear Emulsion Pump consists of one set of precision engineered stator and rotor inside the chamber.

b. The strong centrifugal forces generated by the high speed rotation rotor absorb the materials into the working chamber of the rotor and stator from axial direction.

c. All the materials dispersed, sheared and emulsified by the multi-layers Stator & Rotor and then ejected from the axial direction.

d. Stable finished products with high quality are produced after one time circulation or times.

2. Reference Parameter

a. Power Supply: 380V, 50/60Hz.

b. Seal: Dual End Mechanical Seal ( Pressure Balance Device is optional.)

c. Materials: SS304 or SS316L.

d. Speed: 0-2930 rpm Frequency Converter Control ( Some Model can be customized up to 6000rpm).

e. Flux: 0.5-50 m3/h.

f. Outlet Pressure:≤0.3 MPa.

g. Pipeline Connection: Flange, Quick-connection or Screw

h. Package: Standard Package (Wooden Package).

Model	Motor (kw)	Flow (m³/h)	Speed (rpm)	Inlet (mm)	Outlet (mm)
CLRB1.1/1/6	1.1	0.5	0-2930	DN32	DN25
CLRB2.2/1/6	2.2	3	0-2930	DN40	DN32
CLRB4/1/6	4	5	0-2930	DN40	DN32
CLRB7.5/1/6	7.5	7	0-2930	DN50	DN40
CLRB11/1/6	11	10	0-2930/1450	DN50	DN50
CLRB15/1/6	15	13	0-2930/1450	DN65	DN50
CLRB18.5/1/6	18.5	16	0-2930/1450	DN65	DN50
CLRB22/1/6	22	20	0-2930/1450	DN80	DN65
CLRB30/1/6	30	28	0-2930/1450	DN100	DN80
CLRB37/1/6	37	35	0-2930/1450	DN125	DN100
CLRB45/1/6	45	42	0-2930/1450	DN150	DN125
CLRB55/1/6	55	50	0-2930/1450	DN150	DN125
