CHILE Vacuum high speed paint dispersing mixing machine
- Vacuum High-speed Disperser is a functional machine developed based on the standard High-speed Disperser. A closed lid, with spring seal ring mounted in a milling groove of the cover flange, is completely closed with tank and ensures no air leakage under vacuum operation surroundings.
- Vacuum pumps are option whose limited vacuum degree can be -0.0998mpa(20mbar). It shows excellent performance during special dispersing condition such as vacuum defoaming, vacuum charging, inert gases protection and etc..
- [Materials Viscosity]: ≤100000 cps
- [Production Capacity]: 50-10000L
- [Application Industry]Prefect meet the requirement of dispersing and mixing materials in industries such as biology, pharmaceuticals, food, paint, ink, adhesive, pigment, pesticide and etc..
- [Application Materials]Good for all kinds of slurries with viscosity less than 100,000cps, and solid content less than 60%, such as emulsion paint, industrial paint, water-based ink, pesticide, adhesive and etc.
Technique Parameters:
Model |
Capacity(L) |
Power |
Speed |
Disc Dia(mm) |
Lift(mm) |
Hydraulic Power(kw) |
Weight(kg) |
CLSM-1.5 |
≤50 |
1.5 |
0-1450 |
150 |
600 |
0.55 |
500 |
CLSM-4 |
≤200 |
4 |
0-1450 |
200 |
800 |
0.55 |
700 |
CLSM -7.5 |
≤400 |
7.5 |
0-1450 |
230 |
900 |
0.55 |
800 |
CLSM -11 |
≤500 |
11 |
0-1450 |
250 |
900 |
0.55 |
1100 |
CLSM -15 |
≤700 |
15 |
0-1450 |
280 |
900 |
0.55 |
1200 |
CLSM -18.5 |
≤800 |
18.5 |
0-1450 |
300 |
1100 |
0.75 |
1400 |
CLSM -22 |
≤1000 |
22 |
0-1450 |
350 |
1100 |
0.75 |
1600 |
CLSM -30 |
≤1500 |
30 |
0-1450 |
400 |
1100 |
0.75 |
1800 |
CLSM -37 |
≤2000 |
37 |
0-1450 |
400 |
1600 |
1.1 |
2000 |
CLSM -45 |
≤2500 |
45 |
0-1450 |
450 |
1600 |
1.1 |
2400 |
CLSM -55 |
≤3000 |
55 |
0-1450 |
500 |
1600 |
1.1 |
2600 |
CLSM -75 |
≤4000 |
75 |
0-950 |
550 |
1800 |
2.2 |
2800 |
CLSM -90 |
≤6000 |
90 |
0-950 |
600 |
1800 |
2.2 |
3200 |
CLSM -110 |
≤8000 |
110 |
0-950 |
700 |
2100 |
3 |
3500 |
CLSM -132 |
≤10000 |
132 |
0-950 |
800 |
2300 |
3 |
4000 |
Remarks:
*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*If any changes of the data and picture,no further notice is provided.Correct parameter is based on the real object provided.
*The sheet is not including all the products.To know more information,Pls feel free to contact our sales engineers.
