Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting)

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting)

Name: Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting)
Brand: CHILE
SKU: 103501325
Availability: InStock

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) thumbnail-1

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) thumbnail-2

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) thumbnail-3

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) photo-1

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) photo-2

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting) photo-3

US$ 800 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Agitator

Product Type:

Paint

Contact Supplier Request Quote Chat Now

Chile (Shanghai) Machinery Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Agitator

Product Type Paint

Application Other, solid-solid,liquid-liquid,solid-liquid,air-liquid

Additional Capabilities Other, mixing, dispersing, dissolving

Place of Origin Shanghai, China

Brand Name CHILE

Model Number CLYFS

Max. Loading Capacity 10000L

Voltage 380V 50hz/60hz

Power(W) 1.5~132Kw

Dimension(L*W*H) accordingly

Certification CE; ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Color Paint Disperser Mixer High Speed Dissolver(Hydraulic Lifting)

Product Description

Hydraulic system, stable running, can lift up and down frequently.
Specially made hydraulic cylinder can realize oil-leakage free.
Non-explosion proof/ explosion proof configuration. Explosion proof grade can be customized.
Installation type: ground type/ platform type.
Cover: cover lifting with the headstock
With OMRON/EMERSON inverter.

Technical Parameters:

Model	Capacity (L)	Motor Power (kw)	Speed (rpm)	Disc Dia (mm)	Lifting (mm)	Hydraulic power (kw)	weight (kg)
CLYFS-1.5	≤50	1.5	0-1450	150	600	0.55	400
CLYFS - 4	≤200	4	0-1450	200	800	0.55	600
CLYFS-7.5	≤400	7.5	0-1450	230	900	0.55	800
CLYFS-11	≤500	11	0-1450	250	900	0.55	1000
CLYFS-15	≤700	15	0-1450	280	900	0.55	1100
CLYFS-18.5	≤800	18.5	0-1450	300	1100	0.75	1300
CLYFS-22	≤1000	22	0-1450	350	1100	0.75	1400
CLYFS-30	≤1500	30	0-1450	400	1100	0.75	1500
CLYFS-37	≤2000	37	0-1450	400	1600	1.1	1600
CLYFS-45	≤2500	45	0-1450	450	1600	1.1	1900
CLYFS-55	≤3000	55	0-1450	500	1600	1.1	2100
CLYFS-75	≤4000	75	0-950	550	1800	2.2	2300
CLYFS-90	≤6000	90	0-950	600	1800	2.2	2600
CLYFS-110	≤8000	110	0-950	700	2100	3	3100
CLYFS-132	≤10000	132	0-950	800	2300	3	3600

Remarks:

*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.

*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.

*If any changes of the data and picture,no further notice is provided.Correct parameter is based on the real object provided.

*The sheet is not including all the products.To know more information,Pls feel free to contact our sales engineers.
