Home > Products > HDD&SSD enclosure > USB3.1 Type C Dual mSATA SSD Raid Enclosure (GEN II, 10Gbps) (SSD not included)
USB3.1 Type C Dual mSATA SSD Raid Enclosure (GEN II, 10Gbps) (SSD not included)
- 1000 Piece / Pieces per Month
- Shenzhen or HK
- L/C D/P D/A Credit Card PayPal
You May Like
-
2.5" HDD enclosure USB 3.1 USB3.0 type C to SATA III 6TB HDD/SSD box
-
USB 3.1 Type C 1 Port Metal Bracket with 20 pin USB 3.1 50cm cable and low profile bracket
-
portable 3-in-1 Multifunction Wifi SD / TF Card Reader 3G/4G Wireless Wifi Router USB 2.0 Fast Charger for iPhone /ipad/ Android
-
Multi function 5-in-1 PD charging USB type C combo hub with SD card reader adapter for Macbook Quality Choice
-
Desktop server PCI express x1 to 2port 10/100/1000Mbps 1G Gigabit internet RJ45 lan adapter card
-
2016 new product MULTI 2.4A 8 PORTS USB CHARGING STATION HUB
Product Details
Products Status | Stock | Size | Other, 30*50/30*30mm | |
Case Material | Aluminum | External Interface | Other, USB 3.1 Type C | |
Internal Interface | Other, mSATA | Brand Name | PANTO | |
Model Number | P-LR31-1352S | Place of Origin | Guangdong, China |
Product Description
USB3.1 Type C Dual mSATA SSD Raid Enclosure (GEN II, 10Gbps) (SSD not included)
P-LR31-1352S Specification | |
Model: | P-LR31-1352S |
Product Name: | USB3.1 Type-C TO 2Ports MSATA Raid SSD Enclosure |
Chipset: | ASM1352R+1542 |
Internal interface: | MSATA*2 |
Output interface: | USB3.1 Type C |
Transfer speed: | 10Gbps |
Enclosure material: | aluminum-magnesium alloy |
Product measure: | 100mm* 70mm* 9mm |
Color version: | Gold /silver |
Product weight: | 94g |
Applied SSD version: | 30*30/30*50mm |
Support model: | Raid0(default),Raid1,PM |
OS support: | All WINDOWS/ Linux / Mac (free driver) |
Features:
USB 3.1 a super fast and high-capacity data transfer solution.
Super fast transfer speed (up to 800+MB/s in actual test (RAID 0 mode))
Type C connector cable to fit new MAC Book and PC
Supports 2 mSATA SSD at the same time.
Compliant for USB 3.1 specification.
Data transfer rate up to 10Gbps for USB 3.1.
Compliant for SATA 3.2 specification.
Data transfer rate up to 6.0Gbps for SATA 3.2.
Stable chipset ASM1352R+1542.
Supports RAID0 (default), RAID1 & PM.
Supports 27mm half-height & 50mm full-height SSD.
No capacity limited for SSD card.
2 LED power indicators available.
5V DC jack available for more stable power.
Easy installation & no driver required.
No additional power required.
Support boot function.
Supports Plug & Play and Hot-Swapping.
Supports any OS, like Windows, WinCE, Mac & Linux etc.
Remark:
Please note that it supports mSATA Mini PCI-E SATA SSD only. It does NOT supports Mini PCI-E PATA, 1.8" Micro SATA & Airbook SSD.
Please note that data transfer speed reaches up to 10Gbps only in RAID0 mode, NOT in RAID1 & PM modes.
Package Contents:
1.mSATA SSD Raid Enclosure *1pcs
2.USB3.0 AM To Type-C *1pcs
3.Screwdriver*1pcs
4. Screws *4set
1. We are the factory manufacturer so we can offer you with quite nice factory price.
2. Our products are all in good quality with nice appearance.
3. All of our products are brand new
4. All our products are packed carefully to ensure it is intact when you receive it.
5. OEM is available and are welcomed. You can request to print your logo or other things on the product
by paying us small amount of money.
6. Any questions about us and our products are welcomed. We will answer you with patience.
7. Please kind contact us any time via
Trade Manager: szpanto SKYPE: apscel E-mail: robyhan#
