Fine Rubber Pulverizer

Description:

This type of equipment has the capacity to get 10-20 mesh rubber particles into 40 mesh refined rubber power for
once through water cooling. It is fixed up with a temperature control and alarming system, append carbon black
ground into about 100mesh.

Main parts and usage:
1. Main construction and water cool system
Main electromotor drives grinding tray moving speedy. Subelectromotor drives filled device to fill the material
substance
Temperature would rise when grinding tray moving speedy, it’s not good for work. So configures inner water cool
cycle system to keep the cutting tools work under normal temperature.

2.Rubber powder collect system
The system consists of dust catcher, unload value and fanner linked with disintegrate room. Through fanner, powder
would be collected by negative pressure from the gap of grinding tray smoothly. On the other hand that system can
cool the powder coercive by air to get the balance of thermal

3.Control cabin
Users control the main equipment for single unit or completed assembly line and realize monitor the temperature of
disintegrate room and current load.

Technical parameter:
Model Item                                 260                               280- III
Motor Power (kw)                       76                                   90
Rubber input size (mesh)      10-30                             10-30
Rubber Output Size(mesh)   40-100                           40-100
Capacity (kg/h)                         80-250                         120-350
Dimension (mm)             3500*3500*1200           4200*1300*3500
Weight (kg)                                  4000                             5000
Temperature of Pulverizing     =<70                         =<70 degree

Picture of equipment:
